SS32BF THRU SS320BF
SURFACE MOUNT SCHOTTKY BARRIER RECTIFIER
Forward Current - 3.0 Ampere
Reverse Voltage - 20 to 200 Volts
SMBF
FEATURES
Cathode Band
Top View
0.146(3.70)
0.138(3.50)
Metal silicon junction,majority carrier conduction
For surface mounted applications
Low power loss,high efficiency
High forward surge current capability
For use in low voltage,high frequency inverters,
free wheeling,and polarity protection applicatlons
0.086(2.20)
0.075(1.90)
0.173(4.4)
0.165(4.2)
0.010(0.26)
0.0071(0.18)
0.051(1.30)
0.043(1.10)
0.051(1.30)
0.039(1.0)
MECHANICAL DATA
Case: JEDEC SMBF molded plastic body
Terminals: leads solderable per MIL-STD-750,
Method 2026
Mounting Position: Any
Weight:57mg/0.002oz
0.216(5.5)
0.200(5.1)
Dimensions in inches and (millimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25 C ambient temperature unless otherwise specified.
Single phase half-wave 60Hz,resistive or inductive load,for capacitive load current derate by 20%.
MDD Catalog Number
SYMBOLS SS32BF SS34BF
Marking code
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
at TL(see fig.1)
Peak forward surge current
8.3ms single half sine-wave superimposed on
rated load (JEDEC Method)
Maximum instantaneous forward voltage at 3.0A
Maximum DC reverse current
TA=25 C
at rated DC blocking voltage
TA=100 C
Typical junction capacitance (NOTE 1)
Typical thermal resistance (NOTE 2)
Operating junction temperature range
Storage temperature range
VRRM
VRMS
VDC
SS36BF SS38BF
S32B
S34B
S36B
S38B
S310B
20
14
20
40
28
40
60
42
60
80
56
80
100
70
100
I(AV)
SS315BF SS320BF
S315B
S320B
150
105
150
200
140
200
3.0
IFSM
VF
SS310BF
70.0
IR
CJ
RθJA
TJ,
TSTG
Note:1.Measured at 1MHz and applied reverse voltage of 4.0V D.C.
2.P.C.B. mounted with 0.2x0.2”(5.0x5.0mm) copper pad areas
0.70
VOLTS
VOLTS
VOLTS
Amp
80.0
0.55
UNITS
0.85
0.5
5.0
450
0.95
0.3
3.0
400
50.0
-50 to +125
-50 to +150
Amps
Volts
mA
pF
C/W
C
C
RATINGS AND CHARACTERISTIC CURVES SS32BF THRU SS320BF
Fig.2 Typical Reverse Characteristics
3.5
3.0
2.4
1.8
1.2
Single phase half wave resistive
or inductive P.C.B mounted on
0.5×0.5"(12.7×12.7mm ) pad areas
0.6
0.0
25
50
75
100
125
150
Instaneous Reverse Current ( μA)
Average Forward Current (A)
Fig.1 Forward Current Derating Curve
10 4
T J =100°C
10 3
T J =75°C
10 2
SS32BF/SS36BF
10
T J =25°C
10 0
0
Lead Temperature (°C)
60
100
80
Fig.4 Typical Junction Capacitance
T J =25°C
10
1.0
SS32BF/SS34BF
SS36BF/SS38BF
SS310BF
SS315BF/SS320BF
0.1
0
0.2
0.4
0.6
0.8
1.0
1.2
1.4
1.6
500
200
100
20
SS32BF~SS36BF
SS38BF~SS320BF
10
1.8
0.1
10
1
100
Reverse Voltage (V)
Fig.5 Maximum Non-Repetitive Peak
Forward Surage Current
Fig.6- Typical Transient Thermal Impedance
90
SS32BF-SS38BF
SS310BF-SS320BF
70
60
50
40
8.3 ms Single Half Sine Wave
(JEDEC Method)
20
1
1000
Instaneous Forward Voltage (V)
80
30
Junction Capacitance ( pF)
20
10
Number of Cycles at 60Hz
100
Transient Thermal Impedance( °C /W)
Instaneous Forward Current (A)
40
20
Percent of Rated Peak Reverse Voltage(%)
Fig.3 Typical Forward Characteristic
Peak Forward Surage Current (A)
SS38BF-SS320BF
1
100
10
1
0.01
0.1
1
10
t, Pulse Duration(sec)
The cruve graph is for reference only, can't be the basis for judgment(曲线图仅供参考)!
