SEA & LAND ELECTRONIC CORP. www.sealand-pptc.com ALPHA-TOP TECHNOLOGY CORP. www.alpha-top.cn APPROVAL SHEET MODEL NO.： mSMD Series CUSTOMER： CUSTOMER'S APPROVAL： AUTHORIZED SIGNATURE/STAMP： DATE MANUFACTURER: HEAD OFFICE: China Branch: Submitted by: Approved by: DATE: 13F.,No.120-10,Sec.3,Zhongshan Rd.,Zhonghe Dist.,New Taipei City 23544,Taiwan Tel: 886-2-8221-2567 Fax:882-2-2225-7268 E-mail:service@chipfast.com.tw Factory Building B)Shuangpeng,Weibu Village, Qiuchang Town, Huiyang District, Huizhou City, Guangdong Province, P.R.C.) Tel: 86-752-3562001 Fax:86-752-3558696 E-mail:service@atpptc.com Chen YC Lin 6-Jun-22 SEA & LAND ELECTRONIC CORP. 第1页 Features Applications ■ Surface Mount Devices Almost anywhere there is a low voltage ■ Lead free device power supply, up to 60V and a load to be ■ Size 4.5*3.2 mm/0.18*0.12 inch protected, including: ■ Surface Mount packaging ■ Computer mother board, Modem. USB hub for automated assembly mSMD Series ■ PDAs & Charger, Analog & digital line card ■ Digital cameras, Disk drivers, CD-ROMs, Alpha-Top (Sea & Land Alliance) Performance Specification Maximum Pd Ihold Itrip Time To Trip @25°C @25°C Typ. Current Time (Vdc) (A) (A) (A) (W) (A) (Sec) mSMD010 30 100 0.10 0.30 0.8 0.5 1.50 mSMD010-60V 60 100 0.10 0.30 0.8 0.5 1.50 mSMD014 60 100 0.14 0.34 0.8 1.5 0.15 mSMD020 30 100 0.20 0.40 0.8 8.0 0.02 mSMD020-60V 60 100 0.20 0.40 0.8 8.0 0.02 mSMD030 30 100 0.30 0.60 0.8 8.0 0.10 mSMD030-60V 60 100 0.30 0.60 0.8 8.0 0.10 mSMD050-15V 15 100 0.50 1.00 0.8 8.0 0.15 mSMD050 33 100 0.50 1.00 0.8 8.0 0.15 mSMD050-60V 60 100 0.50 1.00 0.8 8.0 0.15 mSMD075 13.2 100 0.75 1.50 0.8 8.0 0.20 mSMD075-16V 16 100 0.75 1.50 0.8 8.0 0.20 mSMD075-24V 24 100 0.75 1.50 0.8 8.0 0.20 mSMD075-33V 33 100 0.75 1.50 0.8 8.0 0.20 mSMD100 8 100 1.00 1.80 0.8 8.0 0.30 mSMD100-16V 16 100 1.00 1.80 0.8 8.0 0.30 mSMD100-24V 24 100 1.00 1.80 0.8 8.0 0.30 mSMD100-33V 33 100 1.00 1.80 0.8 8.0 0.30 mSMD110 8 100 1.10 2.20 0.8 8.0 0.30 mSMD110-16V 16 100 1.10 2.20 0.8 8.0 0.30 mSMD110-24V 24 100 1.10 2.20 0.8 8.0 0.30 mSMD110-33V 33 100 1.10 2.20 0.8 8.0 0.30 mSMD125 16 100 1.25 2.50 0.8 8.0 0.40 mSMD125-24V 24 100 1.25 2.50 0.8 8.0 0.40 mSMD125-33V 33 100 1.25 2.50 0.8 8.0 0.40 mSMD150 8 100 1.50 3.00 0.8 8.0 0.50 mSMD150-16V 16 100 1.50 3.00 0.8 8.0 0.50 mSMD150-24V 24 100 1.50 3.00 0.8 8.0 0.50 mSMD160 8 100 1.60 2.80 0.8 8.0 1.00 mSMD160-13.2V 13.2 100 1.60 2.80 0.8 8.0 1.00 mSMD160-16V 16 100 1.60 2.80 0.8 8.0 1.00 mSMD200 8 100 2.00 4.00 0.8 8.0 2.00 mSMD200-13.2V 13.2 100 2.00 4.00 0.8 8.0 2.00 mSMD200-16V 16 100 2.00 4.00 0.8 8.0 2.00 mSMD200-24V 24 100 2.00 4.00 0.8 8.0 2.00 mSMD260 8 100 2.60 5.00 0.8 8.0 2.50 mSMD260-13.2V 13.2 100 2.60 5.00 0.8 8.0 2.50 mSMD260-16V 16 100 2.60 5.00 0.8 8.0 2.50 mSMD260-24V 24 100 2.60 5.00 0.8 8.0 2.50 mSMD300-6V 6 100 3.00 5.00 0.8 8.0 4.00 mSMD300 8 100 3.00 5.00 0.8 8.0 4.00 mSMD300-12V 12.0 100 3.00 5.00 0.8 8.0 4.00 mSMD300-13.2V 13.2 100 3.00 5.00 0.8 8.0 4.00 mSMD300-16V 16.0 100 3.00 5.00 0.8 8.0 4.00 mSMD350 6 100 3.50 6.00 2.0 10.0 4.00 mSMD375 6 100 3.75 7.00 2.0 12.0 4.00 mSMD400 6 100 4.00 8.00 2.0 12.0 5.00 Ihold = Hold Current. Maximum current device will not trip in 25°C still air. Itrip = Trip Current. Minimum current at which the device will always trip in 25°C still air. Vmax = Maximum operating voltage device can withstand without damage at rated current (Imax). Imax = Maximum fault current device can withstand without damage at rated voltage (Vmax). Pd = Power dissipation when device is in the tripped state in 25°C still air environment at rated voltage. Rimin/max = Minimum/Maximum device resistance prior to tripping at 25°C. R1max = Maximum device resistance is measured one hour post reflow. Model Vmax Imax CAUTION : Operation beyond the specified ratings may result in damage and possible arcing and flame. 第2页 Resistance Rimin R1max (W) 0.750 0.750 0.650 0.350 0.350 0.250 0.250 0.150 0.150 0.150 0.090 0.090 0.090 0.090 0.055 0.055 0.055 0.055 0.050 0.050 0.050 0.050 0.050 0.050 0.050 0.040 0.040 0.040 0.030 0.030 0.030 0.020 0.020 0.020 0.020 0.015 0.015 0.015 0.015 0.012 0.012 0.012 0.012 0.012 0.008 0.007 0.006 (W) 15.000 15.000 6.000 5.000 5.000 3.000 3.000 1.000 1.000 1.000 0.450 0.450 0.450 0.450 0.270 0.270 0.270 0.270 0.250 0.250 0.250 0.250 0.140 0.140 0.140 0.160 0.160 0.160 0.130 0.130 0.130 0.100 0.100 0.100 0.100 0.050 0.080 0.080 0.080 0.040 0.040 0.040 0.040 0.040 0.030 0.028 0.025 Agency Approval UL TUV √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ Features Applications ■ Surface Mount Devices Almost anywhere there is a low voltage ■ Lead free device power supply, up to 60V and a load to be ■ Size 4.5*3.2 mm/0.18*0.12 inch protected, including: ■ Surface Mount packaging ■ Computer mother board, Modem. USB hub for automated assembly 0.15 ■ PDAs & Charger, Analog & digital line card ■ Digital cameras, Disk drivers, CD-ROMs, Alpha-Top (Sea & Land Alliance) Environmental Specifications Test Conditions Passive aging +85°C, 1000 hrs. Humidity aging +85°C, 85% R.H. , 168 hours Thermal shock +85°C to -40°C, 20 times Resistance to solvent MIL-STD-202,Method 215 Vibration MIL-STD-202,Method 201 Ambient operating conditions : - 40 °C to +85 °C Maximum surface temperature of the device in the tripped state is 125 °C In case of special use,please contact our engineer ` E201504(Alpha-Top)/E319079(Sea&Land) Agency Approvals : R 50481056 Regulation/Standard: 2015/863/EU EN14582 Ihold Versus Temperature Maximum ambient operating temperature (Tmao) vs. hold current (Ihold) Model mSMD010 mSMD014 mSMD020 mSMD030 mSMD050 mSMD075 mSMD100 mSMD110 mSMD125 mSMD150 mSMD160 mSMD200 mSMD260 mSMD300 mSMD350 mSMD375 mSMD400 -40°C 0.16 0.23 0.29 0.44 0.59 1.10 1.45 1.60 2.00 2.30 2.10 2.88 3.90 4.15 4.84 5.45 5.81 -20°C 0.14 0.19 0.26 0.39 0.57 0.99 1.32 1.45 1.75 2.05 1.96 2.61 3.42 3.76 4.39 4.94 5.27 0°C 0.12 0.17 0.23 0.35 0.55 0.87 1.16 1.28 1.52 1.77 1.88 2.25 2.96 3.46 4.04 4.36 4.65 25°C 0.10 0.14 0.20 0.30 0.50 0.75 1.00 1.10 1.25 1.50 1.60 2.00 2.60 3.00 3.50 3.75 4.00 40°C 0.08 0.12 0.17 0.26 0.45 0.63 0.84 0.92 1.00 1.23 1.26 1.80 2.33 2.55 2.98 3.14 3.35 第3页 50°C 0.07 0.10 0.15 0.23 0.43 0.57 0.75 0.83 0.95 1.09 1.12 1.66 2.07 2.28 2.66 2.83 3.02 60°C 0.06 0.09 0.14 0.21 0.35 0.49 0.68 0.71 0.90 0.95 0.98 1.45 1.94 2.01 2.35 2.54 2.71 70°C 0.05 0.08 0.12 0.18 0.30 0.45 0.60 0.66 0.75 0.82 0.84 1.09 1.35 1.61 1.88 2.25 2.40 85°C 0.03 0.06 0.10 0.15 0.23 0.35 0.48 0.52 0.53 0.61 0.63 0.80 1.00 1.33 1.55 1.82 1.94 mSMD Series Alpha-Top (Sea & Land Alliance) Construction And Dimension (Unit:mm) Model Min. 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 4.37 mSMD010 mSMD010-60V mSMD014 mSMD020 mSMD020-60V mSMD030 mSMD030-60V mSMD050-15V mSMD050 mSMD050-60V mSMD075 mSMD075-16V mSMD075-24V mSMD075-33V mSMD100 mSMD100-16V mSMD100-24V mSMD100-33V mSMD110 mSMD110-16V mSMD110-24V mSMD110-33V mSMD125 mSMD125-24V mSMD125-33V mSMD150 mSMD150-16V mSMD150-24V mSMD160 mSMD160-13.2V mSMD160-16V mSMD200 mSMD200-13.2V mSMD200-16V mSMD200-24V mSMD260 mSMD260-13.2V mSMD260-16V mSMD260-24V mSMD300-6V mSMD300 mSMD300-12V mSMD300-13.2V mSMD300-16V mSMD350 mSMD375 mSMD400 A Max. 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73 Min. 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07 B Max. 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 3.41 Dimensions & Marking 0.5 0.5 0.9 D Min. 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 Max. 1.00 1.00 1.00 1.30 1.30 1.00 1.00 0.90 1.60 1.80 0.90 0.90 1.50 1.80 0.90 1.50 1.50 1.80 0.90 1.30 1.60 1.80 1.30 1.30 1.80 0.90 1.30 1.80 0.90 1.30 1.30 1.30 1.30 1.80 1.80 1.30 1.30 1.80 1.80 1.30 1.80 1.80 1.80 1.80 1.3 1.3 1.8 α 1.78 士0.1 3.2士0.1 1.78士0.1 375 D C Recommended Pad Layout (mm) A B Min. 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.40 0.60 0.90 0.40 0.40 0.60 0.90 0.40 0.60 0.60 0.90 0.40 0.60 0.60 0.90 0.60 0.60 0.60 0.40 0.60 0.60 0.40 0.60 0.60 0.60 0.60 0.90 0.90 0.60 0.60 0.90 0.90 0.50 0.90 0.90 0.90 0.90 = Trademark 375 = Hold current E C 3.2士0.1 第4页 E Min. 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.25 mSMD Series 0 Termination Pad Characteristics Terminal pad materials： Tin-plated Nickel-Copper Terminal pad solderability： Meets EIA specification RS186-9E and ANSI/J-STD-002 Category 3. Rework Use standard industry practices, the removal device must be replaced with a fresh one. Thermal Derating Curve Typical Time-To-Trip At 25°C · Use PPTC beyond the maximum ratings or improper use may result in device damage and possible electrical arcing and flame. · PPTC are intended for protection against occasional over current or over temperature fault conditions and should not be used when repeated fault conditions or prolonged trip events are anticipated. · Device performance can be impacted negatively if devices are handled in a manner inconsistent with recommended electronic, thermal, and mechanical procedures for electronic components. · Use PPTC with a large inductance in circuit will generate a circuit voltage (L di/dt) above the rated voltage of the PPTC. · Avoid impact PPTC device its thermal expansion like placed under pressure or installed in limited space. · Contamination of the PPTC material with certain silicon based oils or some aggressive solvents can adversely impact the performance of the devices. PPTC SMD can be cleaned by standard methods. · Requests that customers comply with our recommended solder pad layouts and recommended reflow profile. Improper board layouts or reflow profile could negatively impact solderability performance of our devices. 第5页 mSMD Series Alpha-Top (Sea & Land Alliance) Recommended Solder Reflow Conditions 300 Preheating Soldering Cooling ‧Recommended reflow methods：IR, vapor phase oven, hot air oven. ‧Devices are not designed to be wave soldered to the bottom side 250 of the board. 200 ‧Recommended maximum paste thickness is 0.25 mm (0.010 inch). 190 ‧Devices can be cleaned using standard method and solvents. 160 Note：If reflow temperatures exceed the recommended profile, 100 0 devices may not meet the performance requirements. 60-120 sec. 30~60sec. Tape And Reel Specifications (mm) Governing Specifications W P0 P1 P2 A0 B0 B1max. D0 F E1 E2min. Tmax. T1max. K0 Leader min. Trailer min. Reel Dimensions A max. N min. W1 W2max. 120 sec. EIA Tape Component Dimensions EIA 481-1 12 ± 0.3 4.0 ± 0.10 8.0 ± 0.10 2.0 ± 0.05 3.5 ± 0.23 5.1 ± 0.15 5.9 1.5 + 0.1, -0 5.5 ± 0.05 1.75 ± 0.10 10.25 0.6 0.1 0.9 ± 0.15 390 160 178 60 12.4 + 2.0, -0.0 18.4 P0 T P2 D0 Embossment E1 Cover tape A0 B1 K0 F B0 T1 W E2 P1 EIA Reel Dimensions W2(measured at hub) N(hub dia.) A Cover tape W1(measured at hub) Carrier tape Embossed cavity Storage And Handling ‧ Storage conditions：40°C max, 70% R.H. ‧ Devices may not meet specified performance if storage conditions are exceeded. Order Information mSMD Product name Size 4532mm/1812 inch SMD：surface mount device Tape & reel packaging per EIA481-1 110 Hold Current 1.10A Labeling Information Sea & Land Electronic Corp. Pb Model: Part no.: Spec.: Lot no.: Q'ty: RoHS 倉儲：密封！溫度：18～33℃/濕度：30～60％ A 第6页 Packaging Tape & Reel Quantity mSMD Series 1,500 pcs/reel
