7V24580009

: Serial No. TXC CORPORATION Issue Date www.txccorp.com SPECIFICATION CUSTOMER : PRODUCT TYPE : SMD GLASS SEALING XTAL 3.2 × 2.5 NOMINAL FREQ. : 24.576000MHz TXC P/N : 7V24580009 REVISION : A3 CUSTOMER P/N : Customer Signature & Date (1) TXC requires one copy returned with signature and title of authorized individual that signifies acceptance of the attached specifications. (2) Orders received and accepted by TXC after return of signed copy of specification will be produced per these specifications. (3) Any changes to these specifications must be agreed upon by both parties and new revision of the Product Specification Sheet will be issued. (4) Any issuance of purchase order prior to consigning back the Approval page of "Specification Sheets" from customers will be regarded as the agreement on the contents of these specifications. PE/RD QA MFG Robin Huang Samson Xiong Jake Liu RoHS Compliant FMT-R&D039 Issue Date: 10.16'08 VER.B TXC CORPORATION Rev Revise page S1 N/A S2 3 A1 N/A A2 A3 TXC P/N： 7V24580009 A3 PAGE： 1 Date Ref.No. Reviser Initial released 26-Mar-12 N/A Xiaoyan Jiang Frequency Stability, Drive Level, Equivalent Resistance Rr Change 13-Aug-12 ECR-12N091004 Xiaoyan Jiang S Turn A 3-Sep-12 N/A Xiaoyan Jiang P3~P11 Add SHARP's special requirements Add CKG factory Modify marking code instruction 20-Apr-16 ECR-16N042900 Xiaoyan Jiang P3,4.11 1.Country of origin made in china/TXC chungking factory 2.Making information 3.Add TXC chungking factory 22-Jun-16 ECR-16N062401 Xiaoyan Jiang FMT-DOC024 Revise contents REVISION： Issue Date: 04.17'15 VER.G TXC CORPORATION TXC P/N： 7V24580009 REVISION： A3 PAGE： 2 Spec Sheet Contents No. Content Page 1 ELECTRICAL SPECIFICATIONS P.3 2 DIMENSIONS P.4 3 MARKING P.4 4 FACTORY LOCATION P.4 5 SUGGESTED REFLOW PROFILE& MANUAL SOLDER CONDITION P.4 6 STRUCTURE ILLUSTRATION P.5 7 EMBOSS CARRIER TAPE & REEL P.6 8 PACKING P.7 9 RELIABILITY SPECIFICATIONS FMT-DOC024 P.8～9 Issue Date: 04.17'15 VER.G TXC CORPORATION TXC P/N： 7V24580009 A3 REVISION： PAGE： 3 ■ ELECTRICAL SPECIFICATIONS Standard atmospheric conditions Unless otherwise specified, the standard range of atmospheric conditions for making measurement and tests are as follow: Ambient temperature : 25±5℃ Relative humidity 40%~70% : If there is any doubt about the results, measurement shall be made within the following limits: Ambient temperature : 25±3℃ Relative humidity 40%~70% : Measure equipment Electrical characteristics measured by S&A250B or equivalent. Crystal cutting type The crystal is using AT CUT (thickness shear mode). Unit Weight: 0.018±0.001 g/pcs Country of origin: Made in China/TXC Ningbo Factory Made in China/TXC Chungking Factory Parameters 1 Nominal Frequency 2 Oscillation Mode SYM. Electrical Spec. MIN TYP FL 24.576000 MAX Notes UNITS MHz - - Fundamental - - CL 8 pF - 4 Frequency Tolerance - ±15 ppm at 25 ± 3 ℃ 5 Frequency Stability - ±20 ppm Over Operating Temp. Range (Reference 25℃） 6 Operating Temperature - 7 Aging - 3 Load Capacitance -10 ~ 85 ±3 ℃ ppm 1st Year 8 Drive Level DL - 50 300 uW - 9 Equivalent Resistance Rr Rr - - 50 Ω - 10 Shunt Capacitance C0 C0 - - 3 pF - 11 2 times reflow - - - - - All electric characteristics should be guaranteed after twice reflow. 12 Spurious - - - - - Frequency of 3F0 +/- 100kHz response 3dB or more. 13 Insulation Resistance - 500 - - MΩ 14 Storage Temperature Range - -40 ~ 85 ℃ FMT-DOC024 at DC 100V - Issue Date: 04.17'15 VER.G TXC CORPORATION TXC P/N： 7V24580009 A3 REVISION： PAGE： 4 ■ DIMENSIONS (Unit:mm) 3.2±0.1 Connection 0.25 NC 3 3 4 2.5±0.1 4 1 0.8 ± 0.1 3 Suggested Layout 0.8 1.4 1.4 1.2 0.5 1.2 4 NC 0.7±0.1 2 0.8±0.05 0.9±0.05 1.2±0.1 1 2 1 2 *Coplanarity of solderable areas Camber 0.10 mm Max ■ MARKING 　 TXC Logo T□□□ Frequency Code Ex.: 24.576000 MHz = 245 □□□ Lot Code Date Code Line Code Date Code: MONTH YEAR JAN FEB MAR APR MAY JUN JUL AUG SEP OCT NOV DEC 2005 2009 2013 2017 A B C D E F G H J K L M 2006 2010 2014 2018 N P Q R S T U V W X Y Z 2007 2011 2015 2019 a b c d e f g h j k l m 2008 2012 2016 2020 n p q r s t u v w x y z *This date code will be cycled every four years ■ SUGGESTED REFLOW PROFILE(QCII-P1-06) Pb-free Reflow Profile CONDITION REFLOW PEAK TEMP/TIME 220℃≦ PREHEAT 150 ~ 190℃ MOISUTURE PROOF OPEN-1st REFLOW 1st-2nd Measure Ponit Storage Condition FMT-DOC024 S=REFLOW W=REFLOW 240℃/5s≧ 20 ~ 40s 230℃/5s 20 ~ 40s 90 ~ 120s 90 ~ 120s (It is not necessary ) SURFACE OF COMPONENT 0 ~ 30℃, 70%RH≧ Issue Date: 04.17'15 VER.G TXC CORPORATION TXC P/N： 7V24580009 REVISION： A3 PAGE： 5 ■ STRUCTURE ILLUSTRATION 5 4 6 1 7 2 3 NO MATERIALS COMPONENTS FINISH/SPECIFICATIONS supplier Kyocera - 2 Package Ceramic (AI2O3) Ceramic (AI2O3) Kyocera - 3 PAD Au included in Kyocera base Tungsten metalize 1 Cap +W plating 10~20um + Ni plating 1.27~8.89um + Au plating 0.2~1.0um The substrate(W or Ni) should not be seen due to less Au. 4 Crystal blank SiO2 TXC 5 Conductive adhesive Resin+Ag FUJIKURA - 6 Electrode Noble Metal SOLAR - 7 Sealing Glass Glass(PbO) included in Kyocera base - FMT-DOC024 - Issue Date: 04.17'15 VER.G TXC CORPORATION 7V24580009 TXC P/N： A3 REVISION： PAGE： 6 ■ EMBOSS CARRIER TAPE & REEL F E B H G DIMENSIONS A 1.65±0.10 B Feeding D C A C D E F G H 3.40±0.10 2.70±0.10 4.00±0.10 8.00±0.20 4.00±0.10 1.55±0.10 1.75±0.10 (UNIT：mm) Release strength of cover tape. It has to between 20g～80g under following condition. Pulling Direction : keep angle 165°to 180° Speed : 300mm/Min. TAPE Material TAPE Material Carrier tape ABS or PS Cover tape PS or PET REMARK : Products put in 3000pcs Trailer 160mm(Min) Empty Sealed Leader 160mm(Min) 230mm(Min) User direction of feed W W1 2.0 L1 DIMENSIONS FMT-DOC024 L L L1 W W1 178±1.00 13±0.50 11.5±0.20 8±0.10 (UNIT：mm) Issue Date: 04.17'15 VER.G TXC CORPORATION TXC P/N： 7V24580009 REVISION： A3 PAGE： 7 ■ PACKING Reel Quantity : 1. Reel X 6 (6 Reels) 2. Reel X 12 (12 Reels) 3. Reel X 25 (12 Reels + 13 Reels) 4. Reel X 50 ( 12 Reelsx2 + 13 Reelsx2 ) Label A C-3 Box Size: 1. L200 X W200 X H140mm 2. L200 X W200 X H250mm 3. L400 X W200 X H250mm 4. L400 X W400 X H280mm Tape Tape Label B QA Pass (Label A) Size:80 X 40mm (Label C-3) Size:100 X 50mm (Lable B) Size:100 X 100mm [STORAGE] 1.The storage time to be 1 year maximum. 2.Don't be caught in the rain. 3.The storage environment shall be 5℃ ~40℃ temperature and 30% ~ 75%RH humidity and free from the sun shine. 4.If customers have special requirements, we can paste labels according to it. FMT-DOC024 Issue Date: 04.17'15 VER.G TXC CORPORATION TXC P/N： 7V24580009 REVISION： A3 PAGE： 8 ■ RELIABILITY SPECIFICATIONS ■ It guarantees after reflow twice by pretreatment. Items Conditions Specifications FINE LEAK He bombing 4.5kg/cm2 for 2 hours
