9H03200033

TXC CORPORATION 4F, NO. 16, Sec. 2 Chung Yang S Rd., Peitou, Taipei, Taiwan. TEL : 886-2-2894-1202 , 886-2-2895-2201 FAX : 886-2-2894-1206 , 886-2-2895-6207 www.txccorp.com SPECIFICATION FOR APPROVAL CUSTOMER : PRODUCT TYPE : SMD TUNING FORK 3.2X1.5 NOMINAL FREQ. : 32.768KHz TXC P/N : 9H03200033 REVISION : S1 CUSTOMER P/N : PM / SALES : DATE : CUSTOMER SIGNATURE & Date (1) TXC requires one copy returned with signature and title of authorized individual that signifies acceptance of the attached specifications. (2) Orders received and accepted by TXC after return of signed copy of specification will be produced per these specifications. (3) Any changes to these specifications must be agreed upon by both parties and new revision of the Product Specification Sheet will be issued. (4) Any issuance of purchase order prior to consigning back the Approval page of "Specification Sheets" from customers will be regarded as the agreement on the contents of these specifications. Attachment: Product Specification Sheet 1 2 3 4 5 Halogen Free RoHS Compliant FMT-DOC024 Issue Date: 12.15'08 VER.E TXC CORPORATION 4F, NO. 16, Sec. 2 Chung Yang S Rd., Peitou, Taipei, Taiwan. TEL : 886-2-2894-1202 , 886-2-2895-2201 FAX : 886-2-2894-1206 , 886-2-2895-6207 www.txccorp.com PRODUCT SPECIFICATION SHEET PRODUCT TYPE : SMD TUNING FORK 3.2X1.5 NOMINAL FREQ. : 32.768KHz TXC P/N : 9H03200033 REVISION : S1 RD QA MFG 8-Aug-12 NOTE: (1)Lead Free Products are "Directive 2002/95/EC of The European Parliament of 27 January 2003 on the restriction of the use of certain hazardous substances (RoHS) in electrical and electronic equipment" Compliant (Attachment: SGS Test Report). (2)Revision "Sx" is for engineering samples only. PE/RD's approval required. (3)Revision "Ax" is production ready. PE, QA and MFG's approval required Halogen Free RoHS Compliant FMT-DOC024 Issue Date: 12.15'08 VER.E TXC CORPORATION Rev Revise page S1 NA FMT-DOC024 TXC P/N： 9H03200033 Revise contents Initial release REVISION： S1 PAGE： 1 Date Ref.No. Reviser 8-Aug-12 - Alan Cheng Issue Date: 12.15'08 VER.E TXC P/N： 9H03200033 TXC CORPORATION REVISION： S1 PAGE： 2 ■ ELECTRICAL SPECIFICATIONS Parameters Sym. 1 Nominal Frequency 2 Frequency Tolerance Electrical Spec. Min Typical Max Notes Unit F0 32.768 KHz at 25 ℃ ±3℃ ∆f/fo ± 20 ppm 3 Load Capacitance CL 9.0 pF - 4 Driver Level DL - 0.1 1 μW - ESR - - 70 KΩ at 25 ℃ ±3℃ 6 Turnover Temperature Tp 20 25 30 ℃ 7 Parabolic Curvature Constant K - - -0.04 8 Operating Temperature - -40 ~ 85 ℃ - 9 Storage Temperature - -55 ~ 125 ℃ - 10 Insulation Resistance IR 500 - - MΩ at DC 100V±15V 11 Shunt Capacitance C0 - 1.0 - pF - 12 Motional Capacitance C1 - 3.4 - fF - 13 Aging ∆f/f 5 Equivalent Series Resistance ■ DIMENSIONS at 25 ℃ ±5℃ 2 ppm/℃ - ppm ±3 1st Year ■ RECOMMENDED SOLDER PAD (UNIT:mm) (UNIT:mm) 0.65 1.50 ± 0.10 1.50 ± 0.10 3.20 ± 0.10 1.70 ± 0.10 1.8 0.75 ± 0.10 1.0 ■ SUGGESTED REFLOW PROFILE 1.5 1.0 ■ TEMPERATURE V.S FREQENCY CURVE Total time : 200 sec. Max. -40 Solder melting point :220℃ (℃) 25 85 TEMP (oC) 10 sec 260 220 180 -130 150 △f/fo(ppm) Time (sec) 120 sec FMT-DOC024 60 sec Issue Date: 12.15'08 VER.E REVISION： S1 TXC P/N： 9H03200033 TXC CORPORATION PAGE： 3 ■ MARKING TXC Use Frequency/CL Code Frequency /CL Code KHz PF 32.768 12.5 A 32.768 7.0 B 32.768 9.0 C Date Code CODE XXXXX TXC Use Code Date Code MONTH JAN FEB MAR APR MAY JUN JUL AUG SEP OCT NOV DEC YEAR 2001 2005 2009 2013 2017 A B C D E F G H J K L M 2002 2006 2010 2014 2018 N P Q R S T U V W X Y Z 2003 2007 2011 2015 2019 a b c d e f g h j k l m 2004 2008 2012 2016 2020 n p q r s t u v w x y z This date code will be cycled every four years ■ PACKING Ao= 1.8±0.10 mm Bo= 3.5±0.10 mm L L1 Ko= 1.0±0.10 mm W1 W CARRIER TAPE DIMENSIONS REEL DIMENSIONS REMARK : K1 P0 P1 P2 D0 D1 – 4 4 2 E F 10P0 W 1.55 1.1 1.75 5.5 W W1 16±1.4 13±0.3 L 40 T pcs / Reel 12 0.25 3K L1 180+0/-3 60.2±0.5 1. 230 mm (9.05) minimum leader which consist of carrier and/or tape followed by a minimum of 160 mm (6 (6.3) 3) of empty carrier tape sealed with cover tape tape. 2. 160 mm (6.3) minimum trailer of empty carrier tape sealed with cover tape. FMT-DOC024 Issue Date: 12.15'08 VER.E TXC CORPORATION TXC P/N： 9H03200033 REVISION： S1 PAGE： 4 ■ PACKING Reel Quantity : 1. Reel X 5 (5 Reels x1 ) 2. Reel X 10 (10 Reels x1 ) 3. Reel X 20 (10 Reels x2 ) 4. Reel X 40 (10 Reels x4 ) Label B Box Size: 1. L200 X W200 X H140mm 2. L200 X W200 X H250mm 3. L400 X W200 X H250mm 4. L400 X W400 X H280mm Tape Tape Label A Label B QA Pass (Label A) Size:100 X 100mm (Label B) Size:80 X 40mm [STORAGE] 1.The storage time to be 1 year maximum. 2.Don't be caught in the rain. 3.The storage environment shall be 5℃ ~40℃ temperature and 30% ~ 75%RH humidity and free from the sun shine. 4.If customers have special requirements, we can paste labels according to it. FMT-DOC024 Issue Date: 12.15'08 VER.E TXC CORPORATION TXC P/N： 9H03200033 REVISION： S1 PAGE： 5 ■ STRUCTURE ILLUSTRATION 1 4 6 2 5 NO 1 Lid 3 COMPONENTS MATERIALS FINISH/SPECIFICATIONS Kovar(Fe+Co+Ni) Alloy - 2 Base(Package) Ceramic(AI2O3) Alumina Ceramics 3 PAD Au Tungsten metalize + Ni plating + Au plating 4 Crystal chip SiO2 - 5 Conductive adhesive Ag Silicon resin 6 Electrode Au+Cr - ■ UNIT WEIGHT: 0.01197g/pcs FMT-DOC024 Issue Date: 12.15'08 VER.E TXC P/N： 9H03200033 TXC CORPORATION REVISION： S1 PAGE： 6 ■ RELIABILITY SPECIFICATIONS 1.Mechanical Endurance No. Test Item 1 Drop Test Test Methods REF. DOC MIL-STD-202 150 cm height, fall freely onto concrete floor 3 times. 1 Mechanical Shock 1 Vibration Device are shocked to half sine wave ( 1000 G ) three mutually perpendicular axes each 3 times. 0.5m sec. duration time Frequency range 10 ~ 2000 Hz Amplitude 1.52 mm,20G Sweep time 20 minute Perpendicular axes each test time 4 hours MIL-STD-202 MIL-STD-883 (Total test time 12 hours) 1 Solderability Temperature 245 ℃ ± 5℃ Immersing depth 0.5 mm minimum Immersion time 5 ± 1 seconds Flux Rosin resin methyl y alcohol MIL-STD-883 solvent ( 1 : 4 ) 2.Environmental Endurance No. Test Item 2 Resistance To Soldering Heat Test Methods Pre-heat temperature 125 ℃ Pre-heat time 60 ~ 120 sec. Test temperature 260 ± 5 ℃ Test time 10 ± 1 sec. REF. DOC MIL-STD-202 2 High Temp. Storage + 125 ℃ ± 3 ℃ for 1000 ± 12 hours MIL-STD-883 2 Low Temp. Storage - 40 ℃ ± 3 ℃ for 1000 ± 12 hours MIL-STD-883 Total 100 cycles of the following temperature cycle 1 cycle 2 Thermal Shock 125 ± 3 ℃ MIL-STD-883 25 ℃ -55 ± 3 ℃ 10 min. 10 min. 10 min. max. 3 Pressure Cooker Storage 121 ± 3℃, RH100%, 2 bar, for 240 hours EIA-JESD22 3 High Temp＆Humidity 85℃ ± 3℃, RH 85% , 1000Hrs EIA-JESD22 FMT-DOC024 Issue Date: 12.15'08 VER.E TXC CORPORATION TXC P/N： 9H03200033 REVISION： S1 PAGE： 7 ■ SUGGESTED MANUAL SOLDER CONDITION Temperature: 350 ± 10 ℃ Time: 3 sec. Re-solder times: twice ■ FACTORY LOCATION TXC (NINGBO) CORPORATION NO.189 Huang Shan West Road, Beilun District, Ningbo Zhejiang China FMT-DOC024 Issue Date: 12.15'08 VER.E
