8Z26090001

TXC CORPORATION 4F, NO. 16, Sec. 2 Chung Yang S Rd., Peitou, Taipei, Taiwan. TEL : 886-2-2894-1202 , 886-2-2895-2201 FAX : 886-2-2894-1206 , 886-2-2895-6207 www.txccorp.com SPECIFICATION FOR APPROVAL CUSTOMER : PRODUCT TYPE : SMD SEAM SEALING X'TAL 2.5 × 2.0 NOMINAL FREQ. : 26.000000MHz TXC P/N : 8Z26090001 REVISION : S3 CUSTOMER P/N : PM / SALES : DATE : CUSTOMER SIGNATURE & Date (1) TXC requires one copy returned with signature and title of authorized individual that signifies acceptance of the attached specifications. (2) Orders received and accepted by TXC after return of signed copy of specification will be produced per these specifications. (3) Any changes to these specifications must be agreed upon by both parties and new revision of the Product Specification Sheet will be issued. (4) Any issuance of purchase order prior to consigning back the Approval page of "Specification Sheets" from customers will be regarded as the agreement on the contents of these specifications. Attachment: Product Specification Sheet 1 2 3 4 5 FMT-DOC024 RoHS Compliant Issue Date: 12.15'08 VER.E TXC CORPORATION 4F, NO. 16, Sec. 2 Chung Yang S Rd., Peitou, Taipei, Taiwan. TEL : 886-2-2894-1202 , 886-2-2895-2201 FAX : 886-2-2894-1206 , 886-2-2895-6207 www.txccorp.com PRODUCT SPECIFICATION SHEET PRODUCT TYPE : SMD SEAM SEALING X'TAL 2.5 × 2.0 NOMINAL FREQ. : 26.000000MHz TXC P/N : 8Z26090001 REVISION : S3 PE/RD QA MFG 24-Aug-11 NOTE: (1)Lead Free Products are "Directive 2002/95/EC of The European Parliament of 27 January 2003 on the restriction of the use of certain hazardous substances (RoHS) in electrical and electronic equipment" Compliant (Attachment: SGS Test Report). (2)Revision "Sx" is for engineering samples only. PE/RD's approval required. (3)Revision "Ax" is production ready. PE, QA and MFG's approval required RoHS Compliant FMT-DOC024 Issue Date: 12.15'08 VER.E TXC CORPORATION Rev Revise page S1 N/A S2 S3 FMT-DOC024 TXC P/N： 8Z26090001 Revise contents REVISION： S3 PAGE： 1 Date Ref.No. Reviser Initial released 9-Aug-11 N/A Yachuan Miao 2 Add offset spec:-1.5ppm 10-Aug-11 S11081001 Yachuan Miao 2 Change Freq Tolerance & Cancel offset spec 24-Aug-11 S11082401 Yachuan Miao Issue Date: 12.15'08 VER.E TXC CORPORATION 8Z26090001 TXC P/N： REVISION： S3 PAGE： 2 ■ ELECTRICAL SPECIFICATIONS Standard atmospheric conditions Unless otherwise specified, the standard range of atmospheric conditions for making measurement and tests are as follow: Ambient temperature : 25±10℃ Relative humidity 40%~70% : If there is any doubt about the results, measurement shall be made within the following limits: Ambient temperature : 25±3℃ Relative humidity 40%~70% : Measure equipment Electrical characteristics measured by HP E5100A or equivalent. Crystal cutting type The crystal is using AT CUT (thickness shear mode). Unit Weight: 0.009±0.001 g/pcs Parameters 1 Nominal Frequency 2 Oscillation Mode 3 Load Capacitance Symbol Electrical Spec. Min. Typ. Max. FL 26.000000 MHz - Fundamental - CL 4 Frequency Tolerance - 5 Frequency Stability - 6 Operating Temperature - 7 Aging - -3 4 ±10 -20 ~ - pF 11 -10 Notes Units 75 ±2 - ppm at 25 ℃ ± 3 ℃ ppm Over Operating Temp. Range (Reference 25℃) - ℃ ppm 1st Year DL - 100 - uW - ESR - - 50 Ω - 10 Insulation Resistance - 500 - - MΩ 11 Storage Temperature Range - -40 ~ 85 ℃ 8 Drive Level 9 Equivalent Series Resistance FMT-DOC024 at DC 100V - Issue Date: 12.15'08 VER.E TXC CORPORATION 8Z26090001 TXC P/N： REVISION： S3 PAGE： 3 2.50±0.10 ■ DIMENSIONS (Unit:mm) 4 GND 4 3 2.00±0.10 3 2 2 1 0.55±0.05 1 2 4 1.00 0.65 0.90 1 0.85 0.70±0.10 0.675±0.10 0.725±0.10 Connection GND 3 1.625±0.10 Bottom View Suggest Layout ■ MARKING 　 T□□□ TXC Logo Pin 3 Location ■ Frequency Code ex:14.318180 MHz=143 □□□□ Lot Code Date Code Line Code Date Code: MONTH YEAR 2005 2009 2013 JAN FEB MAR APR MAY JUN JUL AUG SEP OCT NOV DEC 2017 A B C D E F G H J K L M 2006 2010 2014 2018 N P Q R S T U V W X Y Z 2007 2011 2015 2019 a b c d e f g h j k l m 2008 2012 2016 2020 n p q r s t u v w x y z *This date code will be cycled every four years Production location:Taiwan ■ SUGGESTED REFLOW PROFILE Total time : 200 sec. Max. Solder melting point :220 ℃ FMT-DOC024 Issue Date: 12.15'08 VER.E TXC CORPORATION TXC P/N： 8Z26090001 REVISION： S3 PAGE： 4 ■ STRUCTURE ILLUSTRATION 4 5 3 1 2 NO COMPONENTS MATERIALS FINISH/SPECIFICATIONS 1 Lid Kovar (Fe/Co/Ni) 2 Base(Package) Ceramic (AI2O3)+Kovar (Fe/Co/Ni)+Pad (Au) Alumina ceramics 3 Crystal blank SiO2 - 4 Conductive adhesive Ag Silicone resin 5 Electrode Noble Metal - FMT-DOC024 - Issue Date: 12.15'08 VER.E TXC CORPORATION TXC P/N： 8Z26090001 REVISION： S3 PAGE： 5 ■ PACKING REMARK : FMT-DOC024 Issue Date: 12.15'08 VER.E TXC CORPORATION TXC P/N： 8Z26090001 REVISION： S3 PAGE： 6 ■ RELIABILITY SPECIFICATIONS 1.Mechanical Endurance No. Test Item 1.1 Drop Test 1.2 Mechanical Shock 1.3 Vibration Test Methods REF.DOC 150 cm height, 3 times on concrete floor. JIS C6701 Device are shocked to half sine wave ( 1000 G ) three mutually perpendicular axes each 3 times. 0.5m sec. duration time Frequency range 10 ~ 2000 Hz Amplitude 1.52 mm/20G Sweep time 20 minutes perpendicular axes each test time 4 Hrs MIL-STD-202 MIL-STD-883 (Total test time 12 Hrs) 1.4 Gross Leak Standard Sample For Automatic Gross Leak Detector, Test Pressure: 2kg / cm 2 1.5 Fine Leak Helium Bombing 4.5 kg/ cm2 for 2 Hrs 1.6 Solder ability Temperature 245 ℃ ± 5℃ Immersing depth 0.5 mm minimum Immersion time 5 ± 1 seconds Flux Rosin resin methyl alcohol MIL-STD-883 MIL-STD-883 solvent ( 1 : 4 ) 2.Environmental Endurance No. Test Item 2.1 Resistance To Soldering Heat Test Methods Pre-heat temperature 125 ℃ Pre-heat time 60 ~ 120 sec. Test temperature 260 ± 5 ℃ Test time 10 ± 1 sec. 2.2 High Temp. Storage + 125 ℃ ± 3 ℃ for 500 ± 12 Hrs 2.3 Low Temp. Storage - 40 ℃ ± 3 ℃ for 500 ± 12 Hrs REF. DOC MIL-STD-202 MIL-STD-883 Total 100 cycles of the following temperature cycle 2.4 Thermal Shock MIL-STD-883 2.5 High Temp＆Humidity 85℃ ± 3℃, RH 85% , 500Hrs EIA-JESD22 2.6 Pressure Cooker Storage 121 ± 3℃ , RH100% , 2 bar , 240Hrs EIA-JESD22 FMT-DOC024 Issue Date: 12.15'08 VER.E
