MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS
NB series
High reliability, withstand high temperature
Endurance:+130°C 2,000~5,000 hours
Upgrade
NB 130 C
1808
RoHS Compliant
SPECIFICATIONS
Items
Characteristics
Category Temperature Range
-40~+130°C
Rated Voltage Range
10~120 V dc
Capacitance Tolerance
±20%(M)
Leakage Current
I≤0.01CV or 3μA, whichever is greater.
Where, I:Max.leakage current (μA),C:Nominal capacitance (μF),V: Rated voltage (V)
(at 20°C,120Hz)
10
16
25
35
50
63
80
100
120
0.24
0.20
0.18
0.16
0.14
0.12
0.12
0.10
0.12
Rated Voltage(V dc )
10
16
25
35
50
63
80
100
120
Z(-25°C)/Z(+20°C)
3
Z(-40°C)/Z(+20°C)
6
Rated Voltage(V dc )
(at 20°C after 2 minutes)
Dissipation Factor (tanδ)
tanδ (max.)
Low Temperature
Characteristics
(Max. Impedance Ratio)
4
2
3
3
6
(at 20°C,120Hz)
(at 120Hz)
The specifications listed below shall be met when the capacitors are restored to 20°C
after DC voltage plus rated ripple current is applied for a specified period of time at 130°C.
Endurance
Capacitance Change
≤±30% of the initial value
D.F. (tanδ)
≤300% of the initial specified value
Leakage Current
≤The initial specified value
Dia.(mm)
Load life (hours)
ØD=5&6.3
2,000
ØD=8
3,000
ØD=10
4,000
ØD≥12.5
5,000
The following specifications shall be satisfied when the capacitors are restored to 20°C after leaving them under no load
at 130°C for 1,000 hours.
Shelf Life
Capacitance Change
≤±30% of the initial value
D.F. (tanδ)
≤300% of the initial specified value
Leakage Current
≤500% of the initial specified value
DIMENSIONS[mm]
Sleeve(Black)
Ød
ØD'
F±0.5
L'
4min.
15min.
( Ø 5~ Ø 18)
ØD
5
6.3
Ød
F
ØD'
L'
0.5
0.5
2.0
2.5
8
0.5
0.6
3.5
10
12.5
16
18
0.6
0.6
5.0
5.0
0.8
7.5
0.8
7.5
Ø D+0.5max.
L+2max.
E
NB 1H
M 3R3 F11 O- -
Radial Type
PART NUMBERING SYSTEM
T
Sleeve Code: “C” for PVC, “T” for PET
Terminal code
Size code
Capacitance code
Capacitance tolerance code
Voltage code
Series code
Category code
RATED RIPPLE CURRENT MULTIPLIERS
Frequency correction factor for ripple current
Freq.(Hz)
Cap.(μF)
50/60
120
1k
10k
100k
Cap.
