DOSIN-801-0038

A B C D E F Product NO. REV A G DOSIN-801-0038 DESCRIPTION DWN First issue JIM APPROVEN DATE 2012/11/02 John kine 1 1 3 2 SI N Specifications 4 12.5 DO 2 Impedance:50 Ohms Frequency Range:DC~3G VSWR:1.3MAX Working Voltage:500V rms @ sea level Insulation Resistance:5000 Ohms min Relative Temperature: Drawings products are in line with ROHS standards 3 4 PCB 5 6 5 Body 1 Center contact 2 Lead 3 Fixed footrest 4 Insulator 5 Fixed mount 6 Washer 7 Hex nut 8 9 10 NO Component Number A Zinc Brass Iron Iron POM ABS Brass Brass Material B NI:80-120u" NOTE: AU:1u" SN Tolerance NI:80-120u" White DRAWN 2012/11/ White Zelin.Zhang 10 NI:80-120u" View NI:80-120u" CHECKED UNIT APPROVALS SCALE Finish C D 0-6 Dosin Industrial(H.K)Co.Ltd Dosin Hardware Electronics Co.,Ltd Name: E-mail:dosin2005@163.com dosin2005@dosin-china.com Web:http://www.dosinconn.com TEL:(0086)769-81153906 FAX:(0086)769-81875836 BNC WHITE JACK CONNECTOR (12.5MM) 6 REV SIZE Product NO. DOSIN-801-0038 A B DateTime CAD FILE SHEET: 1 OF 1 2012/11/02 D/company drawings/BD MM 1:1 E F G
