DOSIN-801-0081

A B D C E F G Product NO. REV A B 1 2 Tolerance 6 Hex Nut Washer Center Contact Brass TE Brass Nickel Nickel Glod Insulator Body DESCRIPTION Teflon Brass MATERIAL None Nickel FINISH A B APPROVEN John kine 2022/08/09 John kine N I D Specifications Impedance:75 Ohms Frequency Range:DC~3G VSWR:1.3MAX Working Voltage:500V rms @ sea level Insulation Resistance:5000 MOhms min Temperature Range:-55℃ TO +155℃ Relative Temperature:≤95%(40°C±2°C) Drawings products are in line with ROHS standards 5 4 3 2 1 NO DATE 2012/11/02 S O 3 5 DOSIN-801-0081(左右) DWN DESCRIPTION First issue JIM Size 29.5mm changed to 29.2mm, Gavin 14 changed to 13.5 1 1 1 1 1 QTY C 0.5 - 8mm ± 0.20mm 8 - 30mm ± 0.25mm 30 -120mm ± 0.30mm Dosin Industrial(H.K)Co.Ltd Dosin Hardware Electronics Co.,Ltd Name: View UNIT SCALE D dosin2005@dosin-china.com Web:http://www.china-guan.com TEL:(0086)769-81153906 FAX:(0086)769-81875836 R/A BNC JACK FOR PCB CONNECTOR SIZE MM Product NO. A DateTime 1:1 2022/08/09 E REV DOSIN-801-0081(左右) CAD FILE D/company drawings/BD F B SHEET: G 1 OF 1
