DOSIN-801-0052

1 2 3 4 5 6 1 2 3 4 5 6 7 8 9 10 NO A Specifications B Material ZINC POM BARSS Finish NICKEL White GOLD C C APPROVALS DRAWN Zelin.Zhang CHECKED NOTE: Impedance:50 Ohms Frequency Range:DC~3G VSWR:1.3MAX Working Voltage:500V rms @ sea level Insulation Resistance:5000 Ohms min Temperature Range:-55℃ TO +155℃ Relative Temperature:≤95%(40°C±2°C) Drawings products are in line with ROHS standards Body Insulator Center contact Component Number D Tolerance MM E Product NO. REV DESCRIPTION F DWN DOSIN-801-0052 Mr.CHEN W.cheng DATE G 2016/2/04 2021/1/14 APPROVEN John kine John kine E-mail:dosin2005@163.com dosin2005@dosin-china.com Web:http://www.dosinconn.com TEL:(0086)769-81153906 FAX:(0086)769-81875836 BNC JACK CONNECTOR DNN F G REV SIZE Product NO. DOSIN-801-0052 A A DateTime CAD FILE 2016/2/04 H/company drawings/BD SHEET: 1 OF 1 Name: Dosin Hardware Electronics Co.,Ltd 东莞市徳索五金电子制品有限公司 Dosin Industrial(H.K)Co.Ltd First issue First issue E A B X. ±O.30 X.X ±0.25 X.XX ±0.15 Angular ±5° UNIT 1:1 View SCALE D
