DOSIN-811-0677

A B D C E F G Customer NO: DOSIN-811-0677 Mr.CHEN First issue A B 1 DWN DESCRIPTION REV 9.30 APPROVEN DATE 2019/3/22 John kine 1 0 .0 16 2 IN S 4.00 3.50 9.6 11 14.20 3 16.0 11.40 2 3 2.90 RG178 11.0 2.3 20.0 O Specification: Impedance: 50 Ohms VSWR:1.3MAX Frequency range:DC~3G Working Voltage:500V rms @ sea level Insulation resistance:5000 Ohms min Relative temperature: Drawings products are in line with ROHS standards. 4 D 4 5 3.10 5 NOTE: X. Tolerance 6 MMCX R/A PLUG CABLE BNC JACK A BRASS GOLD RG178 BRASS NICKEL B 1 230 1 DRAWN Zelin.chen CHECKED APPROVALS C Name:BNC JACK TO MMCX R/A PLUG FOR RG178 CABLE View UNIT MM SCALE 1:1 D SIZE Product NO. DOSIN-811-0677 A DateTime CAD FILE 2019/3/22 H/company drawings/BD E F REV 6 A SHEET: 1 OF 1 G
