FM24C16D 2-Wire Serial EEPROM
Ver1.4
Data Sheet
2
Description
.Packaging Type
The FM24C16D provides 16384 bits of serial
electrically erasable and programmable read-only
memory (EEPROM) organized as 2048 words of 8
bits each, with 128-bit UID and 16-byte Security
Sector. The device is optimized for use in many
industrial and commercial applications where
low-power and low-voltage operations are essential.
A0
1
8
VCC
A1
2
7
WP
A2
3
6
SCL
GND
4
5
SDA
Low Operation Voltage: VCC = 1.7V to 5.5V
Internally Organized: 2048 x 8
2-wire Serial Interface
Schmitt Trigger, Filtered Inputs for Noise
Suppression
Bi-directional Data Transfer Protocol
1MHz (2.5V~5.5V) and 400 kHz (1.7V)
Compatibility
Write Protect Pin for Hardware Data Protection
16-Byte Page Write Modes (Partial Page
Writes are Allowed)
Lockable 16-Byte Security Sector
128-Bit Unique ID for each device
Self-timed Write Cycle (5 ms max)
High-reliability
– Endurance: 1,000,000 Write Cycles
– Data Retention: 40 Years
PDIP8 (RoHS Compliant)
SOP8, TSSOP8, TSOT23-5L, TDFN8 and Thin
5-ball WLCSP Packages (RoHS Compliant and
Halogen-free)
Wafer Sales: available in Wafer Form
A0
A1
A2
GND
1
8
2
7
3
6
4
5
VCC
WP
SCL
SDA
SCL
1
2
8
7
3
4
6
5
VCC
WP
SCL
SDA
TSSOP8
A0
A1
A2
GND
8
7
6
5
1
2
3
4
VCC
WP
SCL
SDA
1
Thin
Thin 4-ball
4-ball WLCSP
WLCSP 1
TSOT23-5L
WP
VCC
VCC
GND
GND
SCL
SCL
SDA
SDA
GND
SDA
VCC
(TOP
(TOPVIEW)
VIEW)
Module package (6 Pin)
VCC
C1
C5
GND
NC
C2
C6
NC
SCL
C3
C7
SDA
Module package (8 Pin)
VCC
C1
C5
GND
NC
C2
C6
NC
SCL
C3
C7
SDA
NC
C4
C8
NC
Note：
Please contact local sales office for detail description.
Pin Configurations
Absolute Maximum Ratings
Operating Temperature
(Plastic Package)
Storage Temperature
(Plastic Package)
Voltage on Any Pin with Respect
to Ground
Maximum Operating Voltage
DC Output Current
A0
A1
A2
GND
TDFN8 (2x3mm)
Features
SOP8
PDIP8
-55°C to +125°C
Pin Name
Function
A0～A2
SDA
SCL
WP
VCC
GND
Not Connected
Serial Data Input/Output
Serial Clock Input
Write Protect
Power Supply
Ground
-65°C to +150°C
-1.0V to +7.0V
6.25V
5.0 mA
*NOTICE: Stresses beyond those listed under “Absolute
Maximum Ratings” may cause permanent damage to the
device. This is a stress rating only and functional operation of
the device at these or any other conditions beyond those
indicated in the operational sections of this specification are
not implied. Exposure to absolute maximum rating conditions
for extended periods may affect device reliability
FM24C16D 2-Wire Serial EEPROM
Ver1.4
Data Sheet
3
Figure 1．Block Diagram
WP
WRITE PROTECT
LOGIC
EN
HV PUMP & TIMING
CONTROL
LOGIC
HV
DATA WORD
ADDRESS COUNTER
128-bit
Unique
ID
SCL
START STOP LOGIC
SDA
X DECODER
DATA BUFFER
EEPROM
ACK
SEC SECTOR
Din
Dout
DATA
SERIAL MUX
DATA & ACK
INPUT/OUTPUT LOGIC
Y DECODER
OD OUTPUT
FM24C16D 2-Wire Serial EEPROM
Ver1.4
Data Sheet
4
Pin Description
SERIAL CLOCK (SCL): The SCL input is used to
positive edge clock data into each EEPROM device
and negative edge clock data out of each device.
SERIAL DATA (SDA): The SDA pin is bi-directional
for serial data transfer. This pin is open-drain driven
and may be wire-ORed with any number of other
open-drain or open-collector devices.
DEVICE/PAGE ADDRESSES: A total of one device
may be addressed on a single bus system.
WRITE PROTECT (WP): The FM24C16D
has a
Write Protect pin that provides hardware data
protection. The WP pin allows normal write operations
when connected to ground (GND). When the Write
Protect pin is connected to VCC, all write operations
to the memory are inhibited. If the pin is left floating,
the WP pin will be internally pulled down to GND if
the capacitive coupling to the circuit board Vcc plane
is 3pF, FMSH recommends
connecting the WP to GND. Switching WP to VCC
prior to a write operation creates a software write
protected function.
Write Protect Description
WP Pin
Status
Part of the Array Protected
FM 24C16D
WP=VCC
WP=GND
Full (16K) Array
Normal Read/Write Operations
Memory Organization
FM24C16D, 16K SERIAL EEPROM: Internally organized with 128 pages of 16 bytes each, the 16K requires an
11-bit data word address for random word addressing.
Security Sector ： The FM24C16D offers 16-byte Security Sectors which can be written and (later)
permanently locked in Read-only mode. These registers may be used by the system manufacturers to store
security and other important information separately from the main memory array.
Unique ID: The FM24C16D utilizes a separate memory block containing a factory programmed 128-bit
unique ID. Access to this memory location is obtained by beginning the device address word with a „1011‟(Bh)
sequence.
Device Address
WORD Address
Memory Organization
1010 xxxx1
xxxx xxxx2
Data Memory (128 X 16B)
1011 xxxx3
00xx xxxx4
Security Sector (1 X 16B)
5
1011 xxx1
10xx xxxx6
Unique ID (1 X 16B)
Note:
1. The fifth to seventh bits are memory page address bits (P2/P1/P0>) ,and the eighth bit is the read/write
operation select bit.
2. Address bits P2/P1/P0 and A define page address and A define byte address.
3. The fifth to seventh bits are memory page address bits (P2/P1/P0>) ,and the eighth bit is the read/write
operation select bit. P2/P1/P0 are don‟t care.
4. Address bits A must be „00‟, A define byte address, other bits are don‟t care
5. The fifth to seventh bits are memory page address bits (P2/P1/P0) ,and the eighth bit is the read/write
operation select bit. P2/P1/P0 are don‟t care and the read/write operation select bit must be „1‟.
6. Address bits A must be „10‟, A define byte address, other bits are don‟t care
