OB2EL89CLIC112YLC-156.25M

Differential Oscillator YSO230LR Applications Features ‧10 GB Ethernet, SONET, SATA, SAS, Fibre Channel ‧Freq range:13.5MHz-200MHz. ‧Package Size: 2.5*2.0 ,3.2*2.5 , 5.0*3.2 7.0*5.0mm. ‧Output LVPECL or LVDS. Specifications LVPECL Item/Type Output Frequency Range LVDS 7050/5032 3225/2520 7050/5032 3225/2520 13.5~200MHZ 13.5~156.25MHZ 13.5~200MHZ 13.5~156.25MHZ Supply Voltage 2.5V~3.3V Remarks 1.8V, 2.5V~3.3V Operating Temperature Range -40~+85℃,or specify Storage Temperature Range -55~+125℃ Total Stability ±50ppm Current Consumption 80mA Max 50mA Max Disable Current 60mA Max 40mA Max OE=Vcc,LVPECL=(50)Ω or LVDS=(100)Ω 10uA Max Output Voltage (LVPECL) VOH=Vcc-1.03 Min -- VOL=Vcc-1.6 Max -- -- VOD= 247~454mV VOD1, VOD2 -- dVOD=50mV Max. dVOD=|VOD1-VOD2| -- VOS= 1.125~1.375V VOS1, VOS2 dVOS=|VOD1-VOD2| Output Voltage (LVDS) Output Load Condition OE=GND DC characteristics DC characteristics -- dVOS=50mV Max. L_PECL=50Ω -- Terminated to Vcc-2.0V -- L_LVDS=100Ω Connected between OUT to OUT Input Voltage VIH=70% VccMin, VIL=30%Vcc Max Output Symmetry OE terminal 45~55% Rise Time/Fall Time LVPECL: Between 20% and 80% of (VOH-VOL), LVDS:Between 20% and 80% Differential Output peak to peak voltage 0.8nS Max Start-up time 10mS Time at minimum supply voltage to be 0 s Aging ±3ppm 25℃First year, Vcc=2.5V,3.3V 100MHZ Phase Jitter(12KHZ~20MHZ) 125MHZ 148.5MHZ 156.25MHZ 0.3ps Typ. 180MHZ 200MHZ 0.1ps Typ. Pin Dimension Pin #1 #2 #3 #4 #5 #6 FUNCTION OE NC GND OUT+ OUT- VDD Notes: To maintain stable operation provide a 0.01uF to 0.1uF by-pass capacitor at a location as near as possible to the power source terminal of the crystal product (between Vcc-GND). www.yxc.hk 第1页共3页 Differential Oscillator YSO230LR Dimensions and Patterns [unit:mm] Package Size – Dimensions (Unit: mm) Recommended Land Pattern (Unit: mm) 2.5*2.0mm 3.2*2.5mm 5.0*3.2mm 7.0*5.0mm Notes: 1.A capacitor of value 0.01uf~0.1uf or higher between Vdd and GND is required. www.yxc.hk 第2页共3页 Differential Oscillator YSO230LR Reflow Soldering Profile Temperature Pre Heating Temperature Tp1 ~ Tp2 = + 170 °C Heating Temperature TMlt = + 220 °C Peek Temperature TMax. = + 260 °C +260℃ TMax. +220℃ Tmlt Point of measuring In case of Solder ability Terminal. In case of Resistance to soldering heat Surface. Tp2 Tp1 35s 100s t(time) Test Circuit LVDS LVPECL Taping Specification(Unit: mm) Size(OSC) A B C D E F G H SMD-7050 180±2.0 16.0±0.3 7.50±0.1 5.50±0.1 8.0±0.1 2.00±0.1 61.0±1.0 16.0±1.0 SMD-5032 180±2.0 12.0±0.3 5.40±0.1 3.60±0.1 8.0±0.1 1.70±0.1 61.0±1.0 12.0±1.0 SMD-3225 180±2.0 8.0±0.3 3.40±0.1 2.70±0.1 4.0±0.1 1.50±0.1 61.0±1.0 8.0±1.0 SMD-2520 180±2.0 8.0±0.3 2.90±0.1 2.40±0.1 4.0±0.1 1.20±0.1 61.0±1.0 8.0±1.0 www.yxc.hk 第3页共3页
