SN74LVC1G07DBVR

SN74LVC1G07DBVR

  • 厂商:

    UMW(友台)

  • 封装:

    SOT23-5

  • 描述:

    接口(驱动器/接收器/收发器) SOT23-5 1.65V~5.5V

  • 数据手册
  • 价格&库存
SN74LVC1G07DBVR 数据手册
UMW R SN74LVC1G07 Features General Description The SN74LVC1G07 is a high performance single non−inverting buffer with open drain outputs operating from a 1.65 to 5.5V supply. The Output stage is open drain with Over Voltage Tolerance. This allows the SN74LVC1G07 to be used to interface 5.0V circuits to circuits of any voltage between 0 and +7.0V. ● Tiny SC70-5, SOT23-5 and DFN6-1.0mm*1.5mm Packages ● Designed for 1.65V to 5.5V VCC Operation ● 24 mA Output Sink Capability, Pullup may be between 0 and 7.0V ● Near Zero Static Supply Current Substantially Reduces System Power Requirements ● TheseDevic esarePb−Free and RoHS Compliant Pin Configuration Figure1, Top View www.umw-ic.com 1 UTD Semiconductor Co.,Limited UMW R SN74LVC1G07 Pin Function (SC70-5/ SOT23-5) PIN FUNCTION 1 NC 2 IN A 3 GND 4 OUT 5 VCC PIN FUNCTION 1 NC 2 IN A 3 GND 4 OUT 5 NC 6 VCC (DFN6) Block Diagram IN A 1 OUT Y Functional Description Function Table www.umw-ic.com Input Output A Y L L H Z 2 UTD Semiconductor Co.,Limited UMW R SN74LVC1G07 Absolute Maximum Ratings Symbol Parameter Value Unit VCC DC Supply Voltage −0.5 to 7.0 V VI DC Input Voltage −0.5 ≤VI ≤+7.0 V VO DC Output Voltage Output in Higher or Low State (Note 1) −0.5 to VCC + 0.5 V VI < GND −50 mA VOVCC ±50 mA IIK DC Input Diode Current IOK DC Output Diode Current IO DC Output Sink Current ±50 mA ICC DC Supply Current per Supply Pin ±100 mA IGND DC Ground Current per Supply Pin ±100 mA TSTG Storage Temperature Range −65 to 150 ℃ TL Lead Temperature, 1 mm from Case for 10 Seconds 260 ℃ TJ Junction Temperature Under Bias 150 ℃ Thermal Resistance θJA SC70-6 SOT23-6 DFN6 333 225 423 ℃/W PD Power Dissipation in Still Air at 85°C 200 mW MSL Moisture Sensitivity Level 1 ESD Classification Human ESD ILatchup Body Model (Note 2) Machine Model (Note3) Charged Device Model (Note 4) Latchup Performance Above VCC and Below GND at 125°C (Note 5) 2000 200 N/A V ±100 mA Stresses exceeding those listed in the Maximum Ratings table may damage the device. If any of these limits are exceeded, device functionality should not be assumed, damage may occur and reliability may be affected. 1. IO absolute maximum rating must be observed. 2. Tested to EIA/JESD22−A114−A, rated to EIA/JESD22−A114−B. 3. Tested to EIA/JESD22−A115−A, rated to EIA/JESD22−A115−A. 4. Tested to JESD22−C101−A. 5. Tested to EIA/JESD78. Recommended Operating Conditions Symbol Parameter Min Max Unit VCC DC Supply Voltage Operating Date Retention 1.65 1.5 5.5 5.5 V VIN DC Input Voltage 0 5.5 V VOUT DC Output Voltage (High or Low State) 0 5.5 V TA Operating Temperature Range -40 85 ℃ 0 0 0 20 10 5 ns/V Input Rise and Fall Time tr,tf VCC = 2.5 V ± 0.2 V VCC = 3.0 V ± 0.3 V VCC = 5.0 V ± 0.5 V Functional operation above the stresses listed in the Recommended Operating Ranges is not implied. www.umw-ic.com 3 UTD Semiconductor Co.,Limited UMW R SN74LVC1G07 Electrical Characteristics DC ELECTRICAL CHARACTERISTICS Symbol Parameter Condition VCC(V) VIH High−Level Input Voltage 1.65to1.95 2.3 to 5.5 VIL Low−Level Input Voltage 1.65to1.95 2.3 to 5.5 −40℃ ≤TA≤85℃ TA = 25 ℃ Min Typ Max 0.75Vcc 0.7Vcc Min Max 0.75Vcc 0.7Vcc Unit V 0.25Vcc 0.3Vcc 0.25Vcc 0.3Vcc V IOL=100uA 1.65to5.5 0.0 0.1 0.1 IOL=3mA 1.65 0.08 0.24 0.24 IOL=8mA 2.3 0.20 0.3 0.3 IOL=12mA 2.7 0.22 0.4 0.4 IOL=16mA 3.0 0.28 0.4 0.4 IOL=24mA 3.0 0.38 0.55 0.55 IOL=32mA 4.5 0.42 0.55 0.55 IIN Input Leakage Current VIN = 5.5 V or GND 0 to 5.5 ±0.1 ±1.0 uA IOFF Power Off Leakage Current VIN = 5.5 V or VOUT = 5.5 V 0 1 10 uA ICC Quiescent Supply Current VIN = 5.5 V or GND 5.5 1 10 uA VOL Low−Level Output Voltage VIN = VIL V Product parametric performance is indicated in the Electrical Characteristics for the listed test conditions, unless otherwise noted. Product performance may not be indicated by the Electrical Characteristics if operated under different conditions. AC ELECTRICAL CHARACTERISTICS tr=tf= 2.5ns; Symbol tPZL tPLZ Parameter Propagation Delay (Figure3and4) Propagation Delay (Figure3and4) www.umw-ic.com Condition RL= 500Ω CL= 15 pF RL= 500Ω CL= 15 pF −40℃ ≤TA≤85℃ TA = 25 ℃ VCC(V) Min Typ Max Min Max 1.8 2.0 9.1 11.1 2.0 12.8 2.5 1.5 6.1 7.5 1.5 8.5 3.3 1.2 4.9 6.0 1.5 6.9 5.0 0.8 3.9 4.9 0.8 5.5 1.8 2.0 9.1 11.1 2.0 12.8 2.5 1.5 5.9 7.3 1.5 8.3 3.3 1.2 3.9 4.9 1.5 5.5 5.0 0.8 3.0 3.7 0.8 4.2 4 Unit ns ns UTD Semiconductor Co.,Limited UMW R SN74LVC1G07 CAPACITIVE CHARACTERISTICS Symbol Parameter Condition Typical Unit CIN Input Capacitance VCC= 5.5 V, VI = 0 V or VCC >2.5 pF CPD Power Dissipation Capacitance (Note 6) 10 MHz, VCC = 3.3 V, VI = 0 V or VCC 10 MHz,VCC= 5.5 V, VI = 0 V or VCC 26 30 pF 6. CPD is defined as the value of the internal equivalent capacitance which is calculated from the operating current consumption without load. Average operating current can be obtained by the equation: ICC(OPR)=CPD*VCC*fin+ICC*CPD is used to determine the no−load dynamic power consumption; PD=CPD*VCC2*fin+ICC*VCC*Fig. www.umw-ic.com 5 UTD Semiconductor Co.,Limited UMW R SN74LVC1G07 Package Dimension SC70-5 www.umw-ic.com 6 UTD Semiconductor Co.,Limited UMW R SN74LVC1G07 SOT23-5 www.umw-ic.com 7 UTD Semiconductor Co.,Limited UMW R SN74LVC1G07 DFN6 www.umw-ic.com 8 UTD Semiconductor Co.,Limited UMW R SN74LVC1G07 Orderinginformation Order code UMW SN74LVC1G07DBVR UMW SN74LVC1G07DCKR UMW SN74LVC1G07DRYR www.umw-ic.com Marking code C075 CV5 CV Package Baseqty SOT23 5 3000 3000 5000 SC70-5 DFN6 9 Deliverymode Tape and reel Tape and reel Tape and reel UTD Semiconductor Co.,Limited
