AV12000007

TXC CORPORATION 4F, NO. 16, Sec. 2 Chung Yang S Rd., Peitou, Taipei, Taiwan. TEL : 886-2-2894-1202 , 886-2-2895-2201 FAX : 886-2-2894-1206 , 886-2-2895-6207 www.txccorp.com SPECIFICATION FOR APPROVAL CN: 1502002344 CUSTOMER : PRODUCT TYPE : SMD GLASS SEALING X'TAL 3.2*2.5 NOMINAL FREQ. : 12.000000MHz TXC P/N : AV12000007 REVISION : S1 CUSTOMER P/N : PM / SALES : DATE : CUSTOMER SIGNATURE & Date (1) TXC requires one copy returned with signature and title of authorized individual that signifies acceptance of the attached specifications. (2) Orders received and accepted by TXC after return of signed copy of specification will be produced per these specifications. (3) Any changes to these specifications must be agreed upon by both parties and new revision of the Product Specification Sheet will be issued. (4) Any issuance of purchase order prior to consigning back the Approval page of "Specification Sheets" from customers will be regarded as the agreement on the contents of these specifications. MSL:Level 1 RoHS Compliant Pb used in sealing glass material is exempt from EU directive FMT-DOC015 Issue Date: 03.01'13 VER.A TXC CORPORATION 22 TEL : 886-2-2894-1202 , 886-2-2895-2201 FAX : 886-2-2894-1206 , 886-2-2895-6207 www.txccorp.com PRODUCT SPECIFICATION SHEET CN: PRODUCT TYPE : SMD GLASS SEALING X'TAL 3.2*2.5 NOMINAL FREQ. : 12.000000MHz TXC P/N : AV12000007 REVISION : S1 PE/RD QA 1502002344 MFG ZhongLin Wu PREP P PR PREP 12-Feb-15 NOTE: (1)The green product standard set by TXC is based upon the international standards. Related information is publicly described on the TXC's Website, and updated regularly. The document is compliant with the latest green product quality system directives at the time. (2)Revision "Sx" is for engineering samples only. PE/RD's approval required. (3)Revision "Ax" is production ready. PE, QA and MFG's approval required MSL:Level 1 RoHS Compliant Pb used in sealing glass material is exempt from EU directive FMT-DOC015 Issue Date: 03.01'13 VER.A TXC CORPORATION Rev Revise page S1 N/A FMT-DOC015 TXC P/N： Revise contents Initial released AV12000007 S1 REVISION： PAGE： 1 Date Ref.No. Reviser 22-Jan-15 N/A Xiaoyan Jiang Issue Date: 03.01'13 VER.A TXC CORPORATION TXC P/N： AV12000007 REVISION： S1 PAGE： 2 Spec Sheet Contents No. Content Page 1 ELECTRICAL SPECIFICATIONS P.3 2 FACTORY LOCATION P.3 3 DIMENSIONS P.4 4 MARKING P.4 5 SUGGESTED REFLOW PROFILE& MANUAL SOLDER CONDITION P.4 6 STRUCTURE ILLUSTRATION P.5 7 EMBOSS CARRIER TAPE & REEL P.6 8 PACKING P.7 9 RELIABILITY SPECIFICATIONS FMT-DOC015 P.8～9 Issue Date: 03.01'13 VER.A TXC CORPORATION TXC P/N： AV12000007 REVISION： S1 PAGE： 3 ■ ELECTRICAL SPECIFICATIONS Standard atmospheric conditions Unless otherwise specified, the standard range of atmospheric conditions for making measurement and tests are as follow: Ambient temperature : 25±5℃ Relative humidity 40%~70% : If there is any doubt about the results, measurement shall be made within the following limits: Ambient temperature : 25±3℃ Relative humidity 40%~70% : Measure equipment Electrical characteristics measured by S&A250B or equivalent. Crystal cutting type The crystal is using AT CUT (thickness shear mode). Unit Weight: 0.020±0.002 g/pcs Parameters 1 Nominal Frequency 2 Oscillation Mode 3 Load Capacitance 4 SYM. Electrical Spec. MIN TYP FL 12.000000 MAX Notes UNITS MHz - - Fundamental - - CL 8 pF - Frequency Tolerance - ±20 ppm at 25 ℃ ± 3 ℃ 5 Frequency Stability - ±50 ppm Over Operating Temp. Range (Reference 25℃) 6 Operating Temperature - 7 Aging - 8 Drive Level 9 Series Resonant Resistance -40 ~ 125 ±3 ℃ ppm DL - 100 - 1st Year uW - Rr - - 120 Ω - C0 - - 3 pF - 11 Insulation Resistance - 500 - - MΩ 12 Storage Temperature Range - -40 ~ 125 ℃ 10 Shunt Capacitance at DC 100V - ■ FACTORY LOCATION TXC (NINGBO) CORPORATION NO.189 Huang Shan West Road, Beilun District, Ningbo Zhejiang China FMT-DOC015 Issue Date: 03.01'13 VER.A TXC CORPORATION TXC P/N： AV12000007 REVISION： S1 PAGE： 4 ■ DIMENSIONS (Unit:mm) Connection ± #2 & #4 are not internally connected Suggested Layout *Coplanarity of solderable areas Camber 0.10 mm Max ■ MARKING 　 T□□□ TXC Logo Frequency Code Ex.: 12.000000 MHz = 120 □□□ Lot Code Date Code Line Code Date Code: MONTH YEAR JAN FEB MAR APR MAY JUN JUL AUG SEP OCT NOV DEC 2005 2009 2013 2017 A B C D E F G H J K L M 2006 2010 2014 2018 N P Q R S T U V W X Y Z 2007 2011 2015 2019 a b c d e f g h j k l m 2008 2012 2016 2020 n p q r s t u v w x y z *This date code will be cycled every four years (℃) ■ SUGGESTED REFLOW PROFILE Solder melting point :220±10 ℃, 60 sec. Min. Peak Temperature: 260 ± 5 ℃, 10 sec. Max. 10 sec 260 220 180 150 ■ SUGGESTED MANUAL SOLDER CONDITION Temperature: 350 ± 10 ℃ Time (sec) 120 sec 60 sec Time: 3 sec. Re-solder times: twice FMT-DOC015 Issue Date: 03.01'13 VER.A TXC CORPORATION TXC P/N： AV12000007 S1 REVISION： PAGE： 5 ■ STRUCTURE ILLUSTRATION 5 4 6 1 7 2 3 COMPONENTS NO MATERIALS FINISH/SPECIFICATIONS 1 Cap Package Ceramic (AI2O3) Ceramic (AI2O3) - 2 3 PAD Au Tungsten metalize + Ni plating + Au plating 4 Crystal blank SiO2 5 Conductive adhesive Resin+Ag - 6 Electrode Noble Metal - 7 Sealing Glass Glass(PbO) - FMT-DOC015 - Issue Date: 03.01'13 VER.A TXC CORPORATION TXC P/N： AV12000007 S1 REVISION： PAGE： 6 ■ EMBOSS CARRIER TAPE & REEL F E B H G A B Feeding D C A C D E F G H DIMENSIONS 1.65±0.10 3.40±0.10 2.70±0.10 4.00±0.10 8.00±0.20 4.00±0.10 1.55±0.10 1.75±0.10 (UNIT：mm) REMARK : Products put in 3000pcs Trailer 160mm(Min) Empty Sealed Leader 160mm(Min) 230mm(Min) User direction of feed W W1 2.0 L1 L L1 W W1 178±1.00 13±0.50 11.5±0.20 8±0.10 L DIMENSIONS FMT-DOC015 (UNIT：mm) Issue Date: 03.01'13 VER.A TXC CORPORATION TXC P/N： AV12000007 REVISION： S1 PAGE： 7 ■ PACKING Reel Quantity : 1. Reel X 6 (6 Reels) 2. Reel X 12 (12 Reels) 3. Reel X 25 (12 Reels + 13 Reels) 4. Reel X 50 ( 12 Reelsx2 + 13 Reelsx2 ) Label B Box Size: 1. L200 X W200 X H140mm 2. L200 X W200 X H250mm 3. L400 X W200 X H250mm 4. L400 X W400 X H280mm Tape Tape Label B Label A QA Pass (Label A) Size:100 X 100mm (Lable B) Size:80 X 40mm [STORAGE] 1.The storage time to be 1 year maximum. 2.Don't be caught in the rain. 3.The storage environment shall be 5℃ ~40℃ temperature and 30% ~ 75%RH humidity and free from the sun shine. 4.If customers have special requirements, we can paste labels according to it. FMT-DOC015 Issue Date: 03.01'13 VER.A TXC CORPORATION TXC P/N： AV12000007 S1 REVISION： PAGE： ■ RELIABILITY SPECIFICATIONS (AEC-Q200 Compliant) 1.Mechanical Endurance No. 1.1 1.2 Test Item Mechanical Shock Test Methods Test Criteria 2000 G , 0.3 m Sec. ,3 times for all 3 directions. BC Frequency range 10 ~ 2000 Hz Acceleration 20G Amplitude 1.52mm Sweep time 20 minute Pendicular axes each test time 4 hours Vibration BC (Total test time 12 hours) 1.3 Terminal Strength 17.7N force for 60sec +/-1sec. 1.4 Board Flex Duration time:60 Sec Minimum,Deviation:3mm 1.5 Solderability F BC Temperature 245 oC +/- 5oC Immersing depth 0.5 mm minimum Immersion time 5 +/- 0.5 seconds Flux Rosin resin methyl alcohol E solvent ( 1 : 4 ) 2.Environmental Endurance No. Test Item Test Methods SPEC o 2.1 Resistance To Soldering Heat Test temperature 260 +/- 5 C Test time 10 +/- 1 sec. 2.2 High Temp. Storage + 125℃ ± 3 ℃ for 1000 ± 12 Hrs BCD 2.3 Low Temp. Storage - 40 ℃ ± 3 ℃ for 1000 ± 12 Hrs BCD BCD -40℃~125℃,for 1000 cycles. B C D 1 cycle 125+/-3℃ 2.4 Temperature cycle 25 ℃ -40+/-3 ℃ BCD 15 min. 15 min. 2min Max. 1000 hrs @ 125± 3°C. Rated VDD applied with 1 MΩ. 2.5 Operational Life 2.6 High Temp＆Humidity 85℃ ± 3℃ , RH 85% , 1000 Hrs FMT-DOC015 BCD BCD Issue Date: 03.01'13 VER.A 8 put F in ( ℃ B TXC CORPORATION 1 8 0 1 5 0 d i re cti o n D 1000 ) 2 6 0 2 2 0 2 .0 U se r C of W p cs G Emp ty W 1 Se a l e d 1 0 Leader s e c E Pro d u cts 1 6 0 mm(Mi n ) H Tra i l e r IN D EX MAR K A L 1 160 mm ( Mi n) L 230 mm ( Mi n ) fe e d 1 2 0 TXC P/N： Tim s e c e ( s e c ) Fe e d i n g 6 0 s e c AV12000007 REVISION： S1 PAGE： 9 RELIABILITY SPECIFICATIONS Specifications A Frequency change: Within ±5ppm or in customer's specification. B Frequency change: Within ±10ppm or in customer's specification. C Equivalent series resistance(E.S.R) change: Within ±15% or 10Ω(larger value). D After conditioning , quartz crystal units shall be subjected to standard atmospheric conditions for 24 hour, and measured. E Minimum 95% of immersed terminal shall be covered with new uniform solder. F No damage on specimen Measurement condition Electrical characteristics measured by S&A250B or equivalent. FMT-DOC015 Issue Date: 03.01'13 VER.A
