BAS70T

SPICE MODELS: BAS70T BAS70-04T BAS70-05T BAS70-06T BAS70T/ -04T/ -05T/ -06T Lead-free SURFACE MOUNT SCHOTTKY BARRIER DIODE Features · · · · · · · · · · · · · · Low Turn-on Voltage Fast Switching PN Junction Guard Ring for Transient and ESD Protection Ultra-Small Surface Mount Package Lead Free/RoHS Compliant (Note 3) G H K M BC A SOT-523 Dim A B C D G H J K L N Min 0.15 0.75 1.45 ¾ 0.90 1.50 0.00 0.60 0.10 0.10 0.45 0° Max 0.30 0.85 1.75 ¾ 1.10 1.70 0.10 0.80 0.30 0.20 0.65 8° Typ 0.22 0.80 1.60 0.50 1.00 1.60 0.05 0.75 0.22 0.12 0.50 ¾ Mechanical Data Case: SOT-523 Case Material: Molded Plastic. UL Flammability Classification Rating 94V-0 Moisture sensitivity: Level 1 per J-STD-020C Terminals: Finish - Solderable per MIL-STD-202, Method 208 Lead Free Plating (Matte Tin Finish annealed over Alloy 42 leadframe). Polarity: See Diagrams Below Marking: See Diagrams Below & Page 2 Ordering Information, See Page 2 Weight: 0.002 grams (approximate) J D L M N a All Dimensions in mm BAS70T Marking: 7C BAS70-04T Marking: 7D BAS70-05T Marking: 7E BAS70-06T Marking: 7F Maximum Ratings and Electrical Characteristics, Single Diode @ TA = 25°C unless otherwise specified Characteristic Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage RMS Reverse Voltage Forward Continuous Current (Note 1) Non-Repetitive Peak Forward Surge Current @ tp < 1.0s Power Dissipation (Note 1) Thermal Resistance Junction to Ambient Air (Note 1) Operating Temperature Range Storage Temperature Range Symbol VRRM VRWM VR VR(RMS) IFM IFSM Pd RqJA Tj TSTG @ TA = 25°C unless otherwise specified Symbol V(BR)R VF IR CT Min 70 — ¾ ¾ — Max — 410 1000 100 2.0 5.0 Unit — mV nA pF ns Test Condition IR = 10mA tp
