BT134

JIANGSU CHANGJIANG ELECTRONICS TECHNOLOGY CO., LTD TO-126 Plastic-Encapsulate ThyristorS BT134 TRIAC TO-126 1. ANODE FEATURES 2. ANODE Glass passivated triacs in a plastic, intended for use in applications requiring high bidirectional transient and blocking voltage capability and high thermal cycling performance. Typical applications include motor control, industrial and domestic lighting , heating and static switching. 3. GATE T1 T2 G MAXIMUM RATINGS(Ta=25℃ unless otherwise noted) Symbol VDRM/VRRM IT(RMS) Parameter Test conditions Repetitive peak off-state/reverse voltages RMS on-state current Non-repetitive peak on-state current I2t for fusing t=10ms dIT/dt Repetitive rate of rise of on-state current dIG/dt=0.2A/us after tiggering Unit 600 V 4 A full sine wave ;Tmb≦107℃ It 2 Value 3.1 A2s T2+G+ 50 A/us T2+G- 50 A/us T2-G- 50 A/us T2-G+ 10 A/us IGM Peak gate current 2 A VGM Peak gate voltage 5 V PGM Peak gate power 5 W PG(AV) Average gate power 0.5 W Tstg Storage Temperature -40~150 Tj Operating junction Temperature ℃ ℃ www.cj-elec.com over any 20 ms period 125 1 D,Oct,2014 ELECTRICAL CHARACTERISTICS(Ta=25℃ unless otherwise specified) Parameter Symbol Test conditions Rated repetitive peak off-state current IDRM VD=VDRM On-state voltage VTM IT=3A T2(+), G(+) Gate trigger current T2(+), G(-) IGT T2(-), G(-) T2(-), G(+) T2(+), G(+) Gate trigger voltage T2(+), G(-) VGT T2(-), G(-) T2(-), G(+) Holding current Thermal Resistance Junction to mounting base Thermal Resistance Junction to ambient www.cj-elec.com IT=100mA IH Rth j-mb 2 Typ 1.4 VD=12V RL=100Ω VD=12V RL=100Ω IG=20mA Max Unit 10 μA 1.7 V 7 mA 7 mA 7 mA 20 mA 1.45 V 1.45 V 1.45 V 2 V 15 mA full cycle 3.0 K/W half cycle 3.7 K/W In free air Rth j-a Min 60 K/W D,Oct,2014 TO-126 Package Outline Dimensions Symbol A A1 b b1 c D E e e1 h L L1 P Φ www.cj-elec.com Dimensions In Millimeters Min Max 2.500 2.900 1.100 1.500 0.660 0.860 1.170 1.370 0.450 0.600 7.400 7.800 10.600 11.000 2.290 TYP 4.480 4.680 0.000 0.300 15.300 15.700 2.100 2.300 3.900 4.100 3.000 3.200 3 Dimensions In Inches Min Max 0.098 0.114 0.043 0.059 0.026 0.034 0.046 0.054 0.018 0.024 0.291 0.307 0.417 0.433 0.090 TYP 0.176 0.184 0.000 0.012 0.602 0.618 0.083 0.091 0.154 0.161 0.118 0.126 D,Oct,2014
