TO-0812LN

Plug-In Low Noise Amplifier 800 to 1200 MHz Maximum Ratings Operating Temperature Storage Temperature -54°C to 85°C -55°C to 100°C ! NEW TO-0812LN Features • • • • very low noise, 0.8 dB typ. ideal for printed circuit design excellent gain flatness hermetic sealed CASE STYLE: QQ96 PRICE: $199.00 ea. QTY (1-9) Pin Connections RF IN RF OUT DC CASE GND 5 11 2 1,3,4,6,7,8,9,10,12 Applications • military Electrical Specifications MODEL NO. FREQ. (MHz) NF* (dB) GAIN (dB) MAXIMUM POWER INTERCEPT POINT (dBm) (dBm) Output (1 dB Comp.) Typ. +8 Input (no damage) +10 IP3 Typ. +22.5 VSWR (:1) Max. In 2.5 Out 2.5 DC POWER Volt Current (V) (mA) 15 70 fL-fU TO-0812LN 800-1200 Max. 1.2 Min. 20 Flatness Max. ±1.0 *NF specified at room temperature, increases to 1.6 dB max. at +85°C Outline Drawing Typical Performance Data Frequency (MHz) 12V 800.00 850.00 900.00 950.00 1000.00 25.24 25.45 25.57 25.65 25.70 25.78 25.85 25.96 25.99 26.03 Gain (dB) 15V 26.21 26.39 26.47 26.51 26.53 26.59 26.65 26.74 26.78 26.83 Directivity (dB) 16V 26.52 26.68 26.75 26.77 26.78 26.83 26.89 26.98 27.02 27.07 VSWR 16V 25.41 24.15 23.16 22.43 21.75 21.13 20.54 20.06 19.68 19.55 N.F. (dB) OUT 1.84 1.69 1.58 1.52 1.46 1.42 1.40 1.39 1.39 1.39 0.97 0.92 0.92 0.90 0.92 0.90 0.88 0.85 0.85 0.82 Pout (dBm) (@1dB COMPR) 15V 9.27 9.74 9.88 10.22 10.46 10.68 10.88 10.95 10.95 10.95 12V 25.41 24.15 23.16 22.43 21.75 21.13 20.54 20.06 19.68 19.55 15V 25.15 23.86 22.93 22.37 21.94 21.18 20.51 20.16 19.83 19.55 IN 2.21 1.90 1.70 1.59 1.57 1.61 1.71 1.85 1.91 2.01 Outline Dimensions ( inch ) mm A .600 15.24 J .200 5.08 B .250 6.35 K .100 2.54 C .25 6.35 D .016 .41 wt. grams 4.0 E .020 .51 F G .04 .400 1.02 10.16 H .200 5.08 1050.00 1100.00 1150.00 1170.00 1200.00 TO-0812LN GAIN 30 28 GAIN (dB) 26 24 22 20 800 Vcc=15V 35.0 Vcc=15V TO-0812LN DIRECTIVITY 2.5 2.0 1.5 1.0 0.5 Vcc=15V TO-0812LN VSWR DIRECTIVITY (dB) 30.0 VSWR 25.0 20.0 IN OUT 1150 1200 850 900 950 1000 1050 1100 1150 1200 15.0 800 850 900 950 1000 1050 1100 1150 1200 0.0 800 850 900 FREQUENCY (MHz) FREQUENCY (MHz) 950 1000 1050 FREQUENCY (MHz) 1100 Mini-Circuits ® INTERNET http://www.minicircuits.com P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 Distribution Centers NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010 ISO 9001 CERTIFIED REV. OR M89420 EDB-030103 TO-0812LN EL/TD/CP 031103
