MECHATRO N I C D R I V E W I T H S T E P P E R M O T O R
P A Nd r ive
PD- 1 1 4 1
42mm | NEMA 17
Stepper Motor with
Controller / Driver
0.27 - 0.49Nm / 24V
sensOstep™ Encoder
Serial Interface
c o o l S t e p™
sensorless closed loop current control
load detection
M A IN CH A R AC T ER IS T IC S
INFO
The PD42-1141 is a very compact and efficient mechatronic
solution including a 42mm flange motor and a controller/driver
board. It can be controlled via RS485, USB, or step/direction
ELECTRICAL
DATA
MOTOR DATA
INTERFACE
• 9V to 28V DC supply voltage
• flange size 42mm | NEMA17
• RS485, USB
interface or alternatively operated in standalone mode. Power
• step&direction interface
supply, interfaces, and multipurpose inputs and outputs can be
• inputs for ref. & stop switches*
connected with JST connectors.
• 3 general purpose digital inputs*
With the advanced stallGuard2™ feature the motor load can be
• 1 analog input
detected with high resolution. The new outstanding coolStep™
• 2 general purpose outputs
technology for sensorless load dependent current control allows
FEATURES
• up to 256 times microstepping
energy efficient motor operation.
• memory for 2048 TMCL™ commands
The PC based software development environment TMCL-IDE for
• stallGuard2™ sensorless load detection
the Trinamic Motion Control Language TMCL™ can be down-
• coolStep™ sensorless load dependent current control
loaded free of charge from the TRINAMIC website. Predefined
• microPlyer™ 16 to 256 times microstepping
interpolation
high level TMCL commands guarantee a rapid development of
motion control applications.
• automatic ramp generation in hardware
• on the fly alteration of motion parameters
TMCL™
Memory
PD-1141
SOFTWARE
SPI
SPI
USB
RS485
I/Os
6
µC
Power
SPI
Energy
Efficient
Driver
Driver
TMC262
TMC429
Motion
Controller
S/D
TMC262
with
coolStep™
Step
MOSFET
Driver
Stage
• PC-based (Windows) application development software TMCL-IDE downloadable
Motor
OTHER
S/D
• standalone operation using TMCL or remote
controlled operation
• pluggable JST connectors
• RoHS compliant
S/D
• size: 42 x 42 mm2
9… 28V DC
Stop
TMCM-1141
switches
+5V
* alternate functions
ORDER CODE
DESCRIPTION
PD42-1-1141
0.27Nm / QMot motor QSH4218-35-10-027
PD42-2-1141
0.35Nm / QMot motor QSH4218-41-10-035
PD42-3-1141
0.49Nm / QMot motor QSH4218-51-10-049
PD-1141-CABLE
Cable loom including all neccessary cables (single ended)
www.trinamic.com – for detailed information and datasheets
