FIDO1100BGB208IR1

Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller Data Sheet September 10, 2014 fido1100® Data Sheet 32-Bit Real-Time Communications Controller IA211080807-11 UNCONTROLLED WHEN PRINTED OR COPIED Page 1 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller Data Sheet September 10, 2014 Copyright  2017 by Innovasic, Inc. Published by Innovasic, Inc. 5635 Jefferson St. NE, Suite A, Albuquerque, New Mexico 87109 USA fido®, fido1100®, and SPIDER are trademarks of Innovasic, Inc. I2C™ Bus is a trademark of Philips Electronics N.V. Motorola is a registered trademark of Motorola, Inc. IA211080807-11 UNCONTROLLED WHEN PRINTED OR COPIED Page 2 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller Data Sheet September 10, 2014 TABLE OF CONTENTS List of Figures ..................................................................................................................................5 List of Tables ...................................................................................................................................6 1. Overview.................................................................................................................................7 2. Features ...................................................................................................................................9 2.1 Core CPU ....................................................................................................................10 2.2 JTAG ...........................................................................................................................10 2.3 Internal Memory and Memory Management ..............................................................11 2.4 External Bus Interface .................................................................................................12 2.5 PMU/UIC/CPU DMA .................................................................................................12 2.6 Internal Peripherals .....................................................................................................13 2.6.1 Timer Counter Units (TCU) ...........................................................................13 2.6.2 Analog-to-Digital Converter (ADC)...............................................................14 2.6.3 Timers .............................................................................................................14 2.7 Power Control .............................................................................................................14 3. Libraries and Support Tools .................................................................................................15 4. Packaging, Pin Descriptions, and Physical Dimensions .......................................................16 4.1 PQFP Package .............................................................................................................17 4.1.1 PQFP Pinout ...................................................................................................17 4.1.2 PQFP Physical Dimensions ............................................................................24 4.2 BGA 15- by 15-mm Package ......................................................................................25 4.2.1 BGA 15- by 15-mm Pinout.............................................................................25 4.2.2 BGA 15- by 15-mm Physical Package Dimensions .......................................33 4.2.3 BGA 15- by 15-mm Signal Routing ...............................................................34 4.3 Power and Ground Signals ..........................................................................................36 5. Electrical Characteristics ......................................................................................................38 6. Thermal Characteristics ........................................................................................................41 7. Reset .....................................................................................................................................42 7.1 Overview .....................................................................................................................42 7.2 Signal Considerations and Reset Timing ....................................................................42 7.3 Clock Signals...............................................................................................................44 7.4 Typical Clock Source Implementations ......................................................................44 7.4.1 Normal or Driven Clock Source .....................................................................44 7.4.2 Using an External Crystal ...............................................................................44 7.5 Off-Chip Component Value ........................................................................................46 8. Signals...................................................................................................................................47 8.1 External Bus Operation ...............................................................................................47 8.1.1 Overview.........................................................................................................47 IA211080807-11 UNCONTROLLED WHEN PRINTED OR COPIED Page 3 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller 9. 10. 11. 12. 13. 14. Data Sheet September 10, 2014 8.2 General Setup and Hold Timing..................................................................................47 8.3 External Bus Timing ...................................................................................................48 Setup and Hold Timing .........................................................................................................49 9.1.1 External Bus Timing for a 32-Bit Transfer (without RDY_N) ......................51 9.1.2 External Bus Timing for a 32-Bit Transfer (with RDY_N) ...........................52 9.1.3 External Bus Timing for 8-Bit/16-Bit Transfer (without RDY_N) ................54 9.1.4 External Bus Timing for 8-Bit/16-Bit Transfer (with RDY_N) .....................55 9.2 SDRAM Timing ..........................................................................................................56 9.2.1 SDRAM CAS Timing.....................................................................................56 9.2.2 SDRAM Row Activation Timing ...................................................................57 9.2.3 SDRAM Read Operation Timing ...................................................................59 9.2.4 SDRAM Read Burst Timing ..........................................................................59 9.2.5 SDRAM Write Operation, Write Burst, Write-to-Write, and Write-toPrecharge Timing............................................................................................60 JTAG.....................................................................................................................................64 10.1 JTAG Scan Chain Debug Functionality ......................................................................65 Ordering Information ............................................................................................................67 Errata.....................................................................................................................................68 12.1 Summary .....................................................................................................................68 12.2 Detail ...........................................................................................................................68 Revision History ...................................................................................................................72 For Additional Information...................................................................................................74 IA211080807-11 UNCONTROLLED WHEN PRINTED OR COPIED Page 4 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller Data Sheet September 10, 2014 LIST OF FIGURES Figure 1. Block Diagram for the fido1100......................................................................................8 Figure 2. PQFP Package Diagram ................................................................................................17 Figure 3. PQFP Physical Package Dimensions.............................................................................24 Figure 4. BGA 15- by 15-mm Package Diagram .........................................................................26 Figure 5. BGA 15- by 15-mm Physical Package Dimensions ......................................................33 Figure 6. BGA 15- by 15-mm Signal Routing..............................................................................35 Figure 7. Reset Timing .................................................................................................................43 Figure 8. Extended Reset Timing .................................................................................................43 Figure 9. Driven Clock Source .....................................................................................................45 Figure 10. Crystal Oscillator Third Overtone Off-Chip Components .........................................45 Figure 11. Crystal Oscillator Fundamental Overtone Off-Chip Components ..............................45 Figure 12. Propagation Delay .......................................................................................................49 Figure 13. Setup Time...................................................................................................................49 Figure 14. Hold Time ....................................................................................................................50 Figure 15. Recovery Time ............................................................................................................50 Figure 16. Removal Time .............................................................................................................50 Figure 17. Minimum Pulse Width ................................................................................................51 Figure 18. External Bus Timing for a Single, 32-Bit Cycle (without RDY_N) ...........................52 Figure 19. External Bus Timing for a 32-Bit Transfer (with RDY_N) ........................................53 Figure 20. External Bus Timing for 8-Bit/16-Bit Transfer (without RDY_N).............................54 Figure 21. External Bus Timing for 8-Bit/16-Bit Transfer (with RDY_N) ..................................55 Figure 22. SDRAM CAS Timing .................................................................................................57 Figure 23. Specific Row Activation Timing .................................................................................58 Figure 24. Meeting tRCD (min) When 2 < tRCD (min)/tCK ≤ 3 ................................................58 Figure 25. SDRAM Read Operation Timing ................................................................................59 Figure 26. SDRAM Read Burst Timing .......................................................................................60 Figure 27. SDRAM Write Operation Timing ...............................................................................61 Figure 28. SDRAM Write Burst Timing ......................................................................................62 Figure 29. SDRAM Write-to-Write Timing .................................................................................62 Figure 30. SDRAM Write-to-Precharge Timing ..........................................................................63 Figure 31. JTAG State Machine ...................................................................................................64 Figure 32. JTAG Port Register Interface ......................................................................................65 Figure 33. Timing of JTAG Signals .............................................................................................65 IA211080807-11 UNCONTROLLED WHEN PRINTED OR COPIED Page 5 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller Data Sheet September 10, 2014 LIST OF TABLES Table 1. Key Features .....................................................................................................................7 Table 2. Test Pin Descriptions ......................................................................................................11 Table 3. PQFP Pin Listing ............................................................................................................18 Table 4. BGA 15- by 15-mm Package Pin Listing .......................................................................27 Table 5. Analog Power and Ground Signals .................................................................................36 Table 6. Crystal Oscillator Power and Ground Signals ................................................................36 Table 7. 2.5 VDC Digital Core Power Signals .............................................................................36 Table 8. 3.3 VDC Digital IO Power Signals .................................................................................37 Table 9. Digital Ground Signals ...................................................................................................37 Table 10. Absolute Maximum Ratings .........................................................................................38 Table 11. ESD and Latch-Up Characteristics ...............................................................................38 Table 12. Recommended Operating Conditions ...........................................................................38 Table 13. DC Characteristics ........................................................................................................39 Table 14. Input Impedance ............................................................................................................39 Table 15. AC Characteristics of Crystal Oscillator .......................................................................39 Table 16. Analog-to-Digital Converter Characteristics ................................................................40 Table 17. Power Consumption ......................................................................................................40 Table 18. Thermal Resistance Characteristics ..............................................................................41 Table 19. Hardware Signals Involved When Asserting Reset ......................................................42 Table 20. Suggested Off-Chip Component Values .......................................................................46 Table 21. Debug Scan Chain Commands Supported by the JTAG TAP......................................66 Table 22. Part Numbers by Package Types ..................................................................................67 Table 23. Summary of Errata ........................................................................................................68 Table 24. Revision History ...........................................................................................................72 IA211080807-11 UNCONTROLLED WHEN PRINTED OR COPIED Page 6 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller 1. Data Sheet September 10, 2014 Overview Innovasic Semiconductor’s fido1100 is the first product in the fido family of real-time communication controllers. The fido communication controller architecture is uniquely optimized for solving memory bottlenecks, and is designed from the ground up for deterministic processing. Critical timing parameters, such as context switching and interrupt latency, are precisely predictable for real-time tasks. The fido1100 also incorporates the Universal I/O Controller (UIC) that is configurable to support various communication protocols across multiple platforms. This flexibility relieves the designer of the task of searching product matrices to find the set of peripherals that most closely match the system interface needs. The Software Profiling and Integrated Debug EnviRonment (SPIDER) has extensive real-time code debug capabilities without the burden of code instrumentation (see Table 1). Figure 1 illustrates the top-level blocks of the fido1100 architecture. Table 1. Key Features Features • Programmable UIC • • • Five Hardware Contexts Low-Jitter Execution • • • SPIDER Long-Life-Cycle Support • • • Benefits Provides the ability to customize peripherals to match user application. Single chip can solve multiple end-product demands. Reduces costs through optimized inventory management. Runs tight-control loops in separate contexts while RTOS manages high level tasks in another context. Provides context isolation with robust time-and-space partitioning. Performs tasks at much lower clock rates (66MHz versus >200MHz), reducing power budget and simplifying board design. Reduces system integration and debug time through in-system, “what-if” testing without code changes. Reduces firmware development time thus cutting costs. Up to 1Mbyte of trace buffer. Fulfills Innovasic’s corporate policy of supporting products for the customer’s entire life-cycle, eliminating product obsolescence concerns. IA211080807-10 UNCONTROLLED WHEN PRINTED OR COPIED Page 7 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller Data Sheet April 10, 2013 T0IN RREM and MPU T1IN T0IC[3:0] T1IC[3:0] Timer Counter Unit T0OC[3:0] DMA[1:0]_ACK INT[7:0] DMA[1:0]_REQ T1OC[3:0] SPIDER™ Debug A[30:0] D[15:0] CS[7:0]_N RW_N RDY_N HLDREQ_N HLDGNT_N BE[1:0]_N OE_N CPU DMA External Bus Interface Context Manager Priority Control Core CPU SRAM Timers Execution Unit JTAG Debug TDI TDO TCK TMS MEMCLK BA[1:0] CAS_N RAS_N SDRAM Controller Peripheral Management Unit and Frame Buffers CKE 10-Bit 8-Channel ADC UIC_0 UIC_1 UIC_2 UIC_3 UIC0[17:0] UIC1[17:0] UIC2[17:0] UIC3[17:0] AN[7:0] VRH VRL Figure 1. Block Diagram for the fido1100 IA211080807-10 UNCONTROLLED WHEN PRINTED OR COPIED Page 8 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller 2. Data Sheet April 10, 2013 Features The fido1100 communication controller’s features include: • 32-bit Core CPU • CISC architecture optimized for real time • CPU32+ (Motorola® 68000) instruction-set compatible • Five hardware contexts, each with its own register set and interrupt vector table • An 8- or 16-bit external bus interface with programmable chip selects • 24 Kbytes of high-speed internal user SRAM • 32 Kbytes of high-speed internal user-mappable Relocatable Rapid Execution Memory (RREM) • A Memory Protection Unit (MPU) • An SDRAM controller • Flat, contiguous memory space • Non-aligned memory access support • Dedicated Peripheral Management Unit (PMU) • Four Universal I/O Controllers (UICs) capable of supporting the following protocols: – GPIO – 10/100 Ethernet with flexible MAC Address Filtering schemes – EIA-232 – CAN – SPI – I2C Bus – SMBus – HDLC • Two channels of full-featured direct memory access (DMA) with deterministic arbitration • Two Timer/Counter Units (TCU) • A Watchdog timer, system timer, and context timers IA211080807-10 UNCONTROLLED WHEN PRINTED OR COPIED Page 9 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller Data Sheet April 10, 2013 • JTAG emulation and debug interface • Available in 208-pin PQFP and BGA 15- by 15-mm packages • 3.3V operation with 5V-tolerant I/O • Industrial temperature grade • Software development supported by libraries and tools including UIC firmware for various interface protocols and formats, as well as a customized GNU tool set. 2.1 Core CPU The fido1100 core is based on the CPU32 architecture, and is compatible with the CPU32 instruction set. The fido1100 incorporates five independent hardware contexts. While all contexts share the same Execution Unit, each of the five hardware contexts in the fido1100 has its own register set, execution priority and exception vector table. From an application’s view, this unique feature of the fido1100 allows it to operate as five independent machines in one: 2.2 • 32-bit address and data paths on-chip • 66-MHz operation • Instruction execution from external memory or fast internal memory. • Each hardware context has its own copy of: – Eight 32-bit User Data Registers (D0-D7) – Seven 32-bit Address Registers (A0-A6) – Two 32-bit Stack Pointers (A7 and A7') – One 32-bit Program Counter – One 16-bit Status Register (SR) – One 32-bit Vector Base Register (VBR) JTAG The fido1100 is fully compliant with the IEEE 1149.1 Test Access Port and Boundary-Scan architecture (see Table 2). The fido1100 architecture is equipped with the TAP (Test Access Port) interface, TAP controller, instruction register, instruction decoder, boundary-scan register, and by-pass register. IA211080807-10 UNCONTROLLED WHEN PRINTED OR COPIED Page 10 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller Data Sheet April 10, 2013 Table 2. Test Pin Descriptions Pin TDO Direction In TDI TMS In In TCK In Description Test Data Output—The tri-state test data output changing on the falling edge of the TCK input. This is actively driven only in the shift-DR and shift-IR controller states. Test Data Input—The test data input sampled on the rising edge of the TCK input. Test Mode Select Input—The test mode select input used to sequence the TAP controller state machine. If TMS is a 1 for 5 clock cycles, it sends the TAP controller into reset. If TMS is 0, the TAP controller goes to IDLE. Test Clock Input—All JTAG commands and serial data are synchronized by this signal. The JTAG Interface is used for controlling the SPIDER Debug Features of the fido1100. • Breakpoints—Eight hardware context-aware breakpoints that can be chained to set up if/then triggering conditions. – Hardware breakpoints are enabled in software or over JTAG • Watchpoints—Eight hardware watchpoints. • Trace—Follow program execution with trace buffers. – Single address, single buffer, and circular buffer trace modes – Trace buffer can be written anywhere in the address space or to a peripheral • Debug Control—Hardware single-step and context status control. – Access to all memory and registers that are accessible to software – Byte, word, and long-word access in full-address mode or offset mode – Invalid address access (keystroke errors) over JTAG will not kill the session – Direct programming of FLASH on the evaluation board without target software support – Built-in hardware support to halt contexts and execute single instructions without software – JTAG access to registers, stack space, etc., even if the processor is halted • Statistical Profiling—SPIDER provides statistical software profiling to identify critical pieces of code. 2.3 Internal Memory and Memory Management • User SRAM—Internal 24-Kbyte memory that can be used by applications for general purpose data needs or as trace buffers. • Relocatable Rapid Execution Memory (RREM)—Internal 32-Kbyte memory that can be used as an instruction source for code that requires maximum execution speed. IA211080807-10 UNCONTROLLED WHEN PRINTED OR COPIED Page 11 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller • 2.4 Data Sheet April 10, 2013 Memory Protection Unit (MPU)—Access-control method for 16 user-configurable blocks of internal or external memory on a context basis. A block of memory may be inaccessible, read only or read/write accessible to a selectable set of contexts. The MPU provides the space partitioning needed in deterministic, real-time systems. External Bus Interface The interface to all external memory. It handles memory interface timing and arbitration of external bus requests. The external bus interfaces provide all address, data, and control line to implement either an 8- or 16-bit microcontroller system bus. • Address/data bus – 31-bit address bus to access up to 2 Gbytes of memory space – 8- or 16-bit data bus – Zero-overhead Endian conversion • Chip Selects—Eight programmable chip selects with programmable size, data width, and timing. • SDRAM Controller—Supports 8- or 16-bit data interfaces to SDRAM and provides the necessary control signals to interface to external SDRAM. The interface to the external SDRAM uses the 16-bit-wide data bus and 13 bits of the address bus of the External Bus Interface. The dedicated clock signal for this interface (MEMCLK) operates at the same frequency as the internal master clock. – Operates at a maximum clock rate of 66 MHz – Executes read, write, pre-charge, auto refresh, power down, and initialize SDRAM modes – Fixed, 4-word bursts to/from SDRAM interface – Periodically issues auto refresh command to prevent SDRAM data loss • External Bus Arbitration—The fido1100 provides signals to allow it to operate in a multibus master environment. 2.5 PMU/UIC/CPU DMA The PMU, UIC, and CPU DMA work together as a fast data transport scheme that requires minimal Core CPU overhead or intervention. • Peripheral Management Unit (PMU)—A set of user-configurable buffers for data transmission and reception via the UICs. • Universal Input/Output Controller (UIC)—Programmable protocol engine. IA211080807-10 UNCONTROLLED WHEN PRINTED OR COPIED Page 12 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller Data Sheet April 10, 2013 The UIC is a very flexible hardware solution designed to support numerous interface requirements. When working in concert with the on-board Peripheral Management Unit (PMU) and on-board data buffers, the operation of the interfaces requires little core processor intervention. This allows the processor to use its bus bandwidth for more important functions than managing data traffic. The UIC design can support complex protocols such as Ethernet or GPIO functions. • Four software-configurable UICs • Each supports 10/100 Ethernet, CAN, UART, SPI, I2C, HDLC, or GPIO functionality • Software libraries are provided for various interface protocols and formats • User-programmable integrated 256-location MAC address filter • Dedicated PMU offloads main CPU bus traffic • Large 1K × 32 transmit buffer and 2K × 32 receive buffers • At a minimum, each UIC can support 1 Ethernet port (MII), 2 UARTs, or 18 GPIO • CPU DMA—Two independent channels of DMA for data transfer 2.6 Internal Peripherals The fido1100 incorporates the following set of internal peripherals: 2.6.1 • Timer Counter Units (TCU) Two Timer Counter Units (TCU)—The fido1100 is equipped with two Timer Counter Units. – Four channels per timer; any channel can be either input capture or output compare. – Input captures can be either rising or falling edge. – External signal clocking can be rising edge, falling edge, or both edges of input signal. – Output compare can be assert high, assert low, or toggle mode. – Underflow, overflow, input-capture, or output-compare conditions can trigger an interrupt. – Timers can be programmed for auto-stop or auto-reload. – Timer can generate an internal interrupt to wake up the processor from sleep mode. – Timer periods in excess of 50 seconds are achievable. IA211080807-10 UNCONTROLLED WHEN PRINTED OR COPIED Page 13 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller 2.6.2 Analog-to-Digital Converter (ADC) – – – – – – – 2.6.3 2.7 Data Sheet April 10, 2013 8-channel, 10-bit ADC Maximum throughput rate of 200 Kbps High- and low-reference voltage pins ensure accuracy and temperature compensation Very low 5-mW power consumption and includes a built-in power-down mode Single- or multiple-channel conversion scan modes Interrupt generated at the end of conversion is assigned a priority and a context Interrupts from the analog-to-digital converter can be disabled Timers • System Timer. – Provides five periodic System Timer interrupts. o 16-bit counter with 16-bit prescale allows a range of System Timer interrupts from 80 nS to 50 seconds with a 66-MHz system clock. o These interrupts can be assigned to the fast-context switching hardware providing a zero overhead system executive or the System Timer interrupts can simply produce a traditional vectored interrupt request to provide a system with basic timing needs. • Watchdog Timer – 16-bit counter with an 11-bit prescaler • Context Timers – Each hardware context has a set of timing registers that can track, specify, and limit execution time. Power Control All internal peripherals can be put into a low-power consumption mode. IA211080807-10 UNCONTROLLED WHEN PRINTED OR COPIED Page 14 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller 3. Data Sheet April 10, 2013 Libraries and Support Tools • Full library support • UIC libraries • Embedded communication stacks • TCP/IP • GPIO sample programs • Customized GNU tool set • Eclipse IDE • Sourcery G++ from Code Sourcery IA211080807-10 UNCONTROLLED WHEN PRINTED OR COPIED Page 15 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller 4. Data Sheet April 10, 2013 Packaging, Pin Descriptions, and Physical Dimensions Information on the packages and pin descriptions for the fido1100 communication controller PQFP and BGA 15- by 15-mm package is provided individually. Refer to sections, figures, and tables for information on the device of interest. IA211080807-10 UNCONTROLLED WHEN PRINTED OR COPIED Page 16 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller 4.1 PQFP Package 4.1.1 PQFP Pinout Data Sheet April 10, 2013 RESET_N RESET_OUT_N The pinout for the fido1100 communication controller PQFP package is as shown in Figure 2. The corresponding pinout is provided in Table 3. Figure 2. PQFP Package Diagram IA211080807-10 UNCONTROLLED WHEN PRINTED OR COPIED Page 17 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller Data Sheet April 10, 2013 Table 3. PQFP Pin Listing Pin 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 Signal Name AN_7 AN_6 AN_5 AN_4 AN_3 AN_2 AN_1 AN_0 VRL VRH VDDA GNDA INT0 INT1 INT2 VDDC INT3 INT4_DMA0_ ACK INT5_DMA1_ ACK INT6_DMA0_ REQ INT7_DMA1_ REQ VDDIO D0 D1 D2 D3 D4 D5 D6 D7 GND D8 D9 D10 D11 Type Input Input Input Input Input Input Input Input Input Input Power Ground Input Input Input Power Input Bidirectional Description Analog-to-digital converter input channel 7 Analog-to-digital converter input channel 6 Analog-to-digital converter input channel 5 Analog-to-digital converter input channel 4 Analog-to-digital converter input channel 3 Analog-to-digital converter input channel 2 Analog-to-digital converter input channel 1 Analog-to-digital converter input channel 0 Analog-to-digital converter low-input reference Analog-to-digital converter high-input reference Analog supply voltage (+3.3VDC) Analog ground Interrupt_0 Interrupt_1 Interrupt_2 Digital core supply voltage (+2.5VDC) Interrupt_3 Muxed pin, Interrupt_4 or DMA channel 0 acknowledge Bidirectional Muxed pin, Interrupt_5 or DMA channel 1 acknowledge Input Muxed pin, Interrupt_6 or DMA channel 0 request Input Muxed pin, Interrupt_7 or DMA channel 1 request Power Bidirectional Bidirectional Bidirectional Bidirectional Bidirectional Bidirectional Bidirectional Bidirectional Ground Bidirectional Bidirectional Bidirectional Bidirectional Digital I/O supply voltage (+3.3VDC) External Bus Interface data Bit [0] External Bus Interface data Bit [1] External Bus Interface data Bit [2] External Bus Interface data Bit [3] External Bus Interface data Bit [4] External Bus Interface data Bit [5] External Bus Interface data Bit [6] External Bus Interface data Bit [7] Digital ground External Bus Interface data Bit [8] External Bus Interface data Bit [9] External Bus Interface data Bit [10] External Bus Interface data Bit [11] IA211080807-10 UNCONTROLLED WHEN PRINTED OR COPIED Page 18 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller Data Sheet April 10, 2013 Table 3. PQFP Pin Listing (Continued) Pin 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 Signal Name D12 VDDIO D13 D14 D15 RDY_N GND MEMCLK GND BE0_N BE1_N OE_N VDDC RW_N BA_0 BA_1 CAS_N GND RAS_N CKE HOLDREQ_N HOLDGNT_N RESET_N RESET_OUT_N GND A0 A1 A2 A3 VDDIO A4 A5 A6 A7 GND A8 A9 A10 A11 Type Bidirectional Power Bidirectional Bidirectional Bidirectional Input Ground Output Ground Output Output Output Power Output Output Output Output Ground Output Output Input Output Input Output Ground Output Output Output Output Power Output Output Output Output Ground Output Output Output Output Description External Bus Interface data Bit [12] Digital I/O supply voltage (+3.3VDC) External Bus Interface data Bit [13] External Bus Interface data Bit [14] External Bus Interface data Bit [15] External Bus Interface External Ready Indication Digital ground Memory clock used by external memory Digital ground Byte enable 0, active low Byte enable 1, active low Output enable, active low Digital core supply voltage (+2.5VDC) Read or write control (active low write) Bank Enable 0 Bank Enable 1 Column activate signal, active low Digital Ground Row activate signal, active low Clock enable to be used in conjunction with MEMCLK External Bus hold request, active low External Bus grant request, active low Reset input Reset output Digital ground External Bus Interface address Bit [0] External Bus Interface address Bit [1] External Bus Interface address Bit [2] External Bus Interface address Bit [3] Digital I/O supply voltage (+3.3VDC) External Bus Interface address Bit [4] External Bus Interface address Bit [5] External Bus Interface address Bit [6] External Bus Interface address Bit [7] Digital ground External Bus Interface address Bit [8] External Bus Interface address Bit [9] External Bus Interface address Bit [10] External Bus Interface address Bit [11] IA211080807-10 UNCONTROLLED WHEN PRINTED OR COPIED Page 19 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller Data Sheet April 10, 2013 Table 3. PQFP Pin Listing (Continued) Pin 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 Signal Name VDDC A12 A13 A14 A15 VDDC A16 A17 A18 A19 VDDIO A20 A21 A22 A23 GND A24 A25_RESET_ DELAY A26_SIZE 94 A27_CS7_N 95 A28_CS6_N 96 A29_CS5_N 97 A30_CS4_N 98 99 100 101 102 103 104 105 106 107 108 CS0_N CS1_N CS2_N CS3_N TDI TDO TCK TMS VDDC UIC0_0 UIC0_1 Type Power Output Output Output Output Power Output Output Output Output Power Output Output Output Output Ground Output Internal Pull-up Internal Pull-up Output Description Digital core supply voltage (+2.5VDC) External Bus Interface address Bit [12] External Bus Interface address Bit [13] External Bus Interface address Bit [14] External Bus Interface address Bit [15] Digital core supply voltage (+2.5VDC) External Bus Interface address Bit [16] External Bus Interface address Bit [17] External Bus Interface address Bit [18] External Bus Interface address Bit [19] Digital I/O supply voltage (+3.3VDC) External Bus Interface address Bit [20] External Bus Interface address Bit [21] External Bus Interface address Bit [22] External Bus Interface address Bit [23] Digital ground External Bus Interface address Bit [24] Muxed pin, External Bus Interface address Bit [25] or POR counter bypass Muxed pin, External Bus Interface address Bit [26] or data bus size select (0 = 8-Bit, 1= 16=Bit) Muxed pin, External Bus Interface address Bit [27] or Chip select 7 (chip select active low) Output Muxed pin, External Bus Interface address Bit [28] or Chip select 6 (chip select active low) Output Muxed pin, External Bus Interface address Bit [29] or Chip select 5 (chip select active low) Output Muxed pin, External Bus Interface address Bit [30] or Chip select 4 (chip select active low) Output Chip select 0 (chip select active low) Output Chip select 1 (chip select active low) Output Chip select 2 (chip select active low) Output Chip select 3 (chip select active low) Input JTAG data input Output JTAG data output Input JTAG clock input Input JTAG control signal Power Digital core supply voltage (+2.5VDC) Bidirectional Universal I/O Controller 0, pin 0 Bidirectional Universal I/O Controller 0, pin 1 IA211080807-10 UNCONTROLLED WHEN PRINTED OR COPIED Page 20 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller Data Sheet April 10, 2013 Table 3. PQFP Pin Listing (Continued) Pin 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135 136 137 138 139 140 141 142 143 144 145 146 147 Signal Name UIC0_2 UIC0_3 GND UIC0_4 UIC0_5 UIC0_6 UIC0_7 UIC0_8 VDDCLK XTAL0 XTAL1 GNDCLK UIC0_9 UIC0_10 UIC0_11 UIC0_12 UIC0_13 UIC0_14 UIC0_15 UIC0_16 UIC0_17 GND UIC1_0 UIC1_1 UIC1_2 UIC1_3 VDDIO UIC1_4 UIC1_5 UIC1_6 UIC1_7 UIC1_8 UIC1_9 VDDC UIC1_10 UIC1_11 UIC1_12 UIC1_13 UIC1_14 Type Bidirectional Bidirectional Ground Bidirectional Bidirectional Bidirectional Bidirectional Bidirectional Power supply Clock Clock Ground Bidirectional Bidirectional Bidirectional Bidirectional Bidirectional Bidirectional Bidirectional Bidirectional Bidirectional Ground Bidirectional Bidirectional Bidirectional Bidirectional Power Bidirectional Bidirectional Bidirectional Bidirectional Bidirectional Bidirectional Power Bidirectional Bidirectional Bidirectional Bidirectional Bidirectional Description Universal I/O Controller 0, pin 2 Universal I/O Controller 0, pin 3 Digital ground Universal I/O Controller 0, pin 4 Universal I/O Controller 0, pin 5 Universal I/O Controller 0, pin 6 Universal I/O Controller 0, pin 7 Universal I/O Controller 0, pin 8 Power Supply for the Crystal Oscillator (+2.5VDC) Crystal input pin 0 (Osc. In) Crystal input/output pin 1 (Osc. Out) Digital ground Universal I/O Controller 0, pin 9 Universal I/O Controller 0, pin 10 Universal I/O Controller 0, pin 11 Universal I/O Controller 0, pin 12 Universal I/O Controller 0, pin 13 Universal I/O Controller 0, pin 14 Universal I/O Controller 0, pin 15 Universal I/O Controller 0, pin 16 Universal I/O Controller 0, pin 17 Digital ground Universal I/O Controller 1, pin 0 Universal I/O Controller 1, pin 1 Universal I/O Controller 1, pin 2 Universal I/O Controller 1, pin 3 Digital I/O supply voltage (+3.3VDC) Universal I/O Controller 1, pin 4 Universal I/O Controller 1, pin 5 Universal I/O Controller 1, pin 6 Universal I/O Controller 1, pin 7 Universal I/O Controller 1, pin 8 Universal I/O Controller 1, pin 9 Digital core supply voltage (+2.5VDC) Universal I/O Controller 1, pin 10 Universal I/O Controller 1, pin 11 Universal I/O Controller 1, pin 12 Universal I/O Controller 1, pin 13 Universal I/O Controller 1, pin 14 IA211080807-10 UNCONTROLLED WHEN PRINTED OR COPIED Page 21 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller Data Sheet April 10, 2013 Table 3. PQFP Pin Listing (Continued) Pin 148 149 150 151 152 153 154 155 156 157 158 159 160 161 162 163 164 165 166 167 168 169 170 171 172 173 174 175 176 177 178 179 180 181 182 183 184 185 186 Signal Name GND UIC1_15 UIC1_16 UIC1_17 VDDIO UIC2_0 UIC2_1 UIC2_2 UIC2_3 VDDC UIC2_4 UIC2_5 UIC2_6 UIC2_7 GND UIC2_8 UIC2_9 UIC2_10 UIC2_11 VDDIO UIC2_12 UIC2_13 UIC2_14 UIC2_15 GND UIC2_16 UIC2_17 UIC3_0 UIC3_1 VDDC UIC3_2 UIC3_3 UIC3_4 UIC3_5 GND UIC3_6 UIC3_7 UIC3_8 UIC3_9 Type Ground Bidirectional Bidirectional Bidirectional Power Bidirectional Bidirectional Bidirectional Bidirectional Power Bidirectional Bidirectional Bidirectional Bidirectional Ground Bidirectional Bidirectional Bidirectional Bidirectional Power Bidirectional Bidirectional Bidirectional Bidirectional Ground Bidirectional Bidirectional Bidirectional Bidirectional Power Bidirectional Bidirectional Bidirectional Bidirectional Ground Bidirectional Bidirectional Bidirectional Bidirectional Description Digital ground Universal I/O Controller 1, pin 15 Universal I/O Controller 1, pin 16 Universal I/O Controller 1, pin 17 Digital I/O supply voltage (+3.3VDC) Universal I/O Controller 2, pin 0 Universal I/O Controller 2, pin 1 Universal I/O Controller 2, pin 2 Universal I/O Controller 2, pin 3 Digital core supply voltage (+2.5VDC) Universal I/O Controller 2, pin 4 Universal I/O Controller 2, pin 5 Universal I/O Controller 2, pin 6 Universal I/O Controller 2, pin 7 Digital ground Universal I/O Controller 2, pin 8 Universal I/O Controller 2, pin 9 Universal I/O Controller 2, pin 10 Universal I/O Controller 2, pin 11 Digital I/O supply voltage (+3.3VDC) Universal I/O Controller 2, pin 12 Universal I/O Controller 2, pin 13 Universal I/O Controller 2, pin 14 Universal I/O Controller 2, pin 15 Digital ground Universal I/O Controller 2, pin 16 Universal I/O Controller 2, pin 17 Universal I/O Controller 3 pin 0 Universal I/O Controller 3 pin 1 Digital core supply voltage (+2.5VDC) Universal I/O Controller 3 pin 2 Universal I/O Controller 3 pin 3 Universal I/O Controller 3 pin 4 Universal I/O Controller 3 pin 5 Digital ground Universal I/O Controller 3 pin 6 Universal I/O Controller 3 pin 7 Universal I/O Controller 3 pin 8 Universal I/O Controller 3 pin 9 IA211080807-10 UNCONTROLLED WHEN PRINTED OR COPIED Page 22 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller Data Sheet April 10, 2013 Table 3. PQFP Pin Listing (Continued) Pin 187 188 189 190 191 192 193 194 195 196 197 Signal Name VDDIO UIC3_10 UIC3_11 UIC3_12 UIC3_13 GND UIC3_14 UIC3_15 UIC3_16 UIC3_17 T0IC0_T0OC0 Type Power Bidirectional Bidirectional Bidirectional Bidirectional Ground Bidirectional Bidirectional Bidirectional Bidirectional Bidirectional 198 T0IC1_T0OC1 Bidirectional 199 T0IC2_T0OC2 Bidirectional 200 T0IC3_T0OC3 Bidirectional 201 202 GND T1IC0_T1OC0 Ground Bidirectional 203 T1IC1_T1OC1 Bidirectional 204 T1IC2_T1OC2 Bidirectional 205 T1IC3_T1OC3 Bidirectional 206 207 208 VDDC T0IN T1IN Power Input Input Description Digital I/O supply voltage (+3.3VDC) Universal I/O Controller 3 pin 10 Universal I/O Controller 3 pin 11 Universal I/O Controller 3 pin 12 Universal I/O Controller 3 pin 13 Digital Ground Universal I/O Controller 3 pin 14 Universal I/O Controller 3 pin 15 Universal I/O Controller 3 pin 16 Universal I/O Controller 3 pin 17 Muxed pin, Timer Counter Unit 0 input capture 0 or output compare 0 Muxed pin, Timer Counter Unit 0 input capture 1 or output compare 1 Muxed pin, Timer Counter Unit 0 input capture 2 or output compare 2 Muxed pin, Timer Counter Unit 0 input capture 3 or output compare 3 Digital ground Muxed pin, Timer Counter Unit 1 input capture 0 or output compare 0 Muxed pin, Timer Counter Unit 1 input capture 1 or output compare 1 Muxed pin, Timer Counter Unit 1 input capture 2 or output compare 2 Muxed pin, Timer Counter Unit 1 input capture 3 or output compare 3 Digital core supply voltage (+2.5VDC) Timer Counter Unit 0 external clock source Timer Counter Unit 1 external clock source IA211080807-10 UNCONTROLLED WHEN PRINTED OR COPIED Page 23 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller 4.1.2 Data Sheet April 10, 2013 PQFP Physical Dimensions The physical dimensions for the 208-pin PQFP package are as shown in Figure 3. Legend: Symbol A A1 A2 b c D E e HD HE L L1 y Θ Dimension in mm Min Nom Max – – 4.07 0.25 – – 3.15 3.23 3.30 0.18 – 0.28 0.13 – 0.23 27.90 28.00 28.10 27.90 28.00 28.10 0.50 BSC 30.35 30.60 30.85 30.35 30.60 30.85 0.35 0.50 0.65 1.30 REF – – 0.19 0° – 7° Dimension in Inches Min Nom Max – – 0.160 0.010 – – 0.124 0.127 0.130 0.007 – 0.011 0.005 – 0.009 1.098 1.102 1.106 1.098 1.102 1.106 0.020 BSC 1.195 1.205 1.215 1.195 1.205 1.215 0.014 0.020 0.026 0.051 REF – – 0.004 0° – 7° Notes: 1. Dimension D & E do not include interlead flash. 2. Dimension B does not include damper protrusion/intrusion. 3. Controlling dimension: mm 4. General appearance spec. should be based on visual inspection spec. Figure 3. PQFP Physical Package Dimensions IA211080807-10 UNCONTROLLED WHEN PRINTED OR COPIED Page 24 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller 4.2 BGA 15- by 15-mm Package 4.2.1 BGA 15- by 15-mm Pinout Data Sheet April 10, 2013 The pinout for the fido1100 communication controller BGA 15- by 15-mm package is as shown in Figure 4. The corresponding pinout is provided in Table 4. IA211080807-10 UNCONTROLLED WHEN PRINTED OR COPIED Page 25 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller 1 T1IC1_ A T1OC1 2 T0IC2_ T0OC2 T1IC2_ T1OC2 3 4 T0IC0_ UIC3_15 T0OC0 T1IC0_ T0IC1_ T1OC0 T0OC1 T1IC3_ T0IN T1OC3 5 UIC3_13 6 7 12 13 14 UIC3_7 UIC3_4 UIC3_1 UIC3_0 UIC2_15 UIC2_13 UIC2_10 UIC2_7 UIC2_6 UIC1_17 UIC3_11 UIC3_8 UIC3_5 UIC3_2 UIC2_17 UIC2_14 UIC2_11 UIC2_8 UIC2_5 UIC2_0 UIC1_14 B UIC3_17 UIC3_14 UIC3_10 UIC3_6 UIC3_3 UIC2_16 UIC2_12 UIC2_9 UIC2_4 UIC2_1 UIC1_16 UIC1_12 C VDDIO GND GND UIC2_2 UIC1_13 UIC1_9 D UIC3_12 UIC3_9 9 10 11 15 16 17 A AN_2 C AN_0 AN_5 D VDDA AN_1 AN_6 GND E GNDA VRH AN_3 GND GND UIC1_15 UIC1_10 UIC1_6 E F INT2 INT0 VRL AN_7 UIC2_3 UIC1_11 UIC1_8 UIC1_5 F INT3 INT1 AN_4 VDDIO UIC1_7 UIC1_4 UIC1_2 G INT5_ DMA1_ VDDC ACK VDDIO UIC1_3 UIC1_1 UIC1_0 H INT6_ DMA0_ REQ T0IC3_ T0OC3 GND GND 8 B INT4_ G DMA0_ ACK INT7_ H DMA1_ REQ UIC3_16 Data Sheet April 10, 2013 T1IN VDDC VDDC VDDC VDDIO VDDIO J D0 D1 D2 VDDIO VDDIO UIC0_17 UIC0_16 UIC0_15 J K D3 D4 D6 VDDIO VDDC UIC0_14 UIC0_13 UIC0_12 K L D5 D7 D11 OE_N VDDC UIC0_10 UIC0_9 UIC0_11 L M D8 D10 D15 CAS_N GNDCLK VDDCLK UIC0_8 XTAL1 M N D9 D13 BE1_N GND GND UIC0_5 UIC0_7 XTAL0 N P D12 RDY_N BA_1 GND GND UIC0_0 UIC0_4 UIC0_6 P R D14 BE0_N BA_0 RAS_N HOLDGNT_N A3 A6 A10 A15 A18 A22 T GND RW_N CKE RESET_ OUT_N A2 A5 A8 A11 A14 A17 A20 A24 A0 A1 A4 A7 A9 A12 A13 A16 A19 A23 3 4 5 6 7 8 9 10 11 12 U MEMCLK HOLDREQ_N 1 2 GND GND RESET_N VDDIO VDDC VDDC A21 A26_SIZE GND A27_CS7_N A29_CS5_N A28_CS6_N CS3_N CS2_N CS0_N CS1_N TCK TDI TDO TMS 15 16 17 A25_RESET_ A30_CS4_N DELAY 13 14 UIC0_2 UIC0_3 R UIC0_1 T U = Signals. = Indicates power. = Indicates ground. Figure 4. BGA 15- by 15-mm Package Diagram IA211080807-10 UNCONTROLLED WHEN PRINTED OR COPIED Page 26 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller Data Sheet September 10, 2014 Table 4. BGA 15- by 15-mm Package Pin Listing Pin F4 D3 C2 G4 E3 B1 D2 C1 F3 E2 D1 E1 F2 G3 F1 D7 G2 G1 H3 H2 H1 D10 J1 J2 J3 K1 K2 L1 K3 L2 D4 M1 N1 M2 L3 Signal Name AN_7 AN_6 AN_5 AN_4 AN_3 AN_2 AN_1 AN_0 VRL VRH VDDA GNDA INT0 INT1 INT2 VDDC INT3 INT4_DMA0_ ACK INT5_DMA1_ ACK INT6_DMA0_ REQ INT7_DMA1_ REQ VDDIO D0 D1 D2 D3 D4 D5 D6 D7 GND D8 D9 D10 D11 Type Input Input Input Input Input Input Input Input Input Input Power Ground Input Input Input Power Input Bidirectional Description Analog-to-digital converter input channel 7 Analog-to-digital converter input channel 6 Analog-to-digital converter input channel 5 Analog-to-digital converter input channel 4 Analog-to-digital converter input channel 3 Analog-to-digital converter input channel 2 Analog-to-digital converter input channel 1 Analog-to-digital converter input channel 0 Analog-to-digital converter low-input reference Analog-to-digital converter high-input reference Analog supply voltage (+3.3VDC) Analog ground Interrupt_0 Interrupt_1 Interrupt_2 Digital core supply voltage (+2.5VDC) Interrupt_3 Muxed pin, Interrupt_4 or DMA channel 0 acknowledge Bidirectional Muxed pin, Interrupt_5 or DMA channel 1 acknowledge Input Muxed pin, Interrupt_6 or DMA channel 0 request Input Muxed pin, Interrupt_7 or DMA channel 1 request Power Bidirectional Bidirectional Bidirectional Bidirectional Bidirectional Bidirectional Bidirectional Bidirectional Ground Bidirectional Bidirectional Bidirectional Bidirectional Digital I/O supply voltage (+3.3VDC) External Bus Interface data Bit [0] External Bus Interface data Bit [1] External Bus Interface data Bit [2] External Bus Interface data Bit [3] External Bus Interface data Bit [4] External Bus Interface data Bit [5] External Bus Interface data Bit [6] External Bus Interface data Bit [7] Digital ground External Bus Interface data Bit [8] External Bus Interface data Bit [9] External Bus Interface data Bit [10] External Bus Interface data Bit [11] IA211080807-11 UNCONTROLLED WHEN PRINTED OR COPIED Page 27 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller Data Sheet September 10, 2014 Table 4. BGA 15- by 15-mm Package Pin Listing (Continued) Pin P1 D11 N2 R1 M3 P2 T1 U1 D5 R2 N3 L4 D8 T2 R3 P3 M4 P6 R4 T3 U2 R5 P7 T4 D13 U3 U4 T5 R6 D12 U5 T6 R7 U6 D14 T7 U7 R8 Signal Name D12 VDDIO D13 D14 D15 RDY_N GND MEMCLK GND BE0_N BE1_N OE_N VDDC RW_N BA_0 BA_1 CAS_N GND RAS_N CKE HOLDREQ_N HOLDGNT_N RESET_N RESET_OUT_N GND A0 A1 A2 A3 VDDIO A4 A5 A6 A7 GND A8 A9 A10 Type Bidirectional Power Bidirectional Bidirectional Bidirectional Input Ground Output Ground Output Output Output Power Output Output Output Output Ground Output Output Input Output Input Output Ground Output Output Output Output Power Output Output Output Output Ground Output Output Output Description External Bus Interface data Bit [12] Digital I/O supply voltage (+3.3VDC) External Bus Interface data Bit [13] External Bus Interface data Bit [14] External Bus Interface data Bit [15] External Bus Interface External Ready Indication Digital ground Memory clock used by external memory Digital ground Byte enable 0, active low Byte enable 1, active low Output enable, active low Digital core supply voltage (+2.5VDC) Read or write control (active low write) Bank Enable 0 Bank Enable 1 Column activate signal, active low Digital Ground Row activate signal, active low Clock enable to be used in conjunction with MEMCLK External Bus hold request, active low External Bus grant request, active low Reset input Reset output Digital ground External Bus Interface address Bit [0] External Bus Interface address Bit [1] External Bus Interface address Bit [2] External Bus Interface address Bit [3] Digital I/O supply voltage (+3.3VDC) External Bus Interface address Bit [4] External Bus Interface address Bit [5] External Bus Interface address Bit [6] External Bus Interface address Bit [7] Digital ground External Bus Interface address Bit [8] External Bus Interface address Bit [9] External Bus Interface address Bit [10] IA211080807-11 UNCONTROLLED WHEN PRINTED OR COPIED Page 28 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller Data Sheet September 10, 2014 Table 4. BGA 15- by 15-mm Package Pin Listing (Continued) Pin T8 D9 U8 U9 T9 R9 H4 U10 T10 R10 U11 G14 T11 P11 R11 U12 E4 T12 U13 P12 Signal Name A11 VDDC A12 A13 A14 A15 VDDC A16 A17 A18 A19 VDDIO A20 A21 A22 A23 GND A24 A_25_RESET_ DELAY A_26_SIZE R12 A27_CS7_N Type Output Power Output Output Output Output Power Output Output Output Output Power Output Output Output Output Ground Output Internal Pull-up Internal Pull-up Output T13 A28_CS6_N Output R13 A29_CS5_N Output U14 A30_CS4_N Output T14 T15 R15 R14 U15 U16 T16 U17 K14 CS0_N CS1_N CS2_N CS3_N TDI TDO TCK TMS VDDC Output Output Output Output Input Output Input Input Power Description External Bus Interface address Bit [11] Digital core supply voltage (+2.5VDC) External Bus Interface address Bit [12] External Bus Interface address Bit [13] External Bus Interface address Bit [14] External Bus Interface address Bit [15] Digital core supply voltage (+2.5VDC) External Bus Interface address Bit [16] External Bus Interface address Bit [17] External Bus Interface address Bit [18] External Bus Interface address Bit [19] Digital I/O supply voltage (+3.3VDC) External Bus Interface address Bit [20] External Bus Interface address Bit [21] External Bus Interface address Bit [22] External Bus Interface address Bit [23] Digital ground External Bus Interface address Bit [24] Muxed pin, External Bus Interface address Bit [25] or POR counter bypass Muxed pin, External Bus Interface address Bit [26] or data bus size select (0 = 8-Bit, 1= 16=Bit) Muxed pin, External Bus Interface address Bit [27] or Chip select 7 (chip select active low) Muxed pin, External Bus Interface address Bit [28] or Chip select 6 (chip select active low) Muxed pin, External Bus Interface address Bit [29] or Chip select 5 (chip select active low) Muxed pin, External Bus Interface address Bit [30] or Chip select 4 (chip select active low) Chip select 0 (chip select active low) Chip select 1 (chip select active low) Chip select 2 (chip select active low) Chip select 3 (chip select active low) JTAG data input JTAG data output JTAG clock input JTAG control signal Digital core supply voltage (+2.5VDC) IA211080807-11 UNCONTROLLED WHEN PRINTED OR COPIED Page 29 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller Data Sheet September 10, 2014 Table 4. BGA 15- by 15-mm Package Pin Listing (Continued) Pin P15 T17 R16 R17 E14 P16 N15 P17 N16 M16 M15 N17 M17 M14 L16 L15 L17 K17 K16 K15 J17 J16 J15 N4 H17 H16 G17 H15 J4 G16 F17 E17 G15 F16 D17 L14 E16 F15 Signal Name UIC0_0 UIC0_1 UIC0_2 UIC0_3 GND UIC0_4 UIC0_5 UIC0_6 UIC0_7 UIC0_8 VDDCLK XTAL0 XTAL1 GNDCLK UIC0_9 UIC0_10 UIC0_11 UIC0_12 UIC0_13 UIC0_14 UIC0_15 UIC0_16 UIC0_17 GND UIC1_0 UIC1_1 UIC1_2 UIC1_3 VDDIO UIC1_4 UIC1_5 UIC1_6 UIC1_7 UIC1_8 UIC1_9 VDDC UIC1_10 UIC1_11 Type Bidirectional Bidirectional Bidirectional Bidirectional Ground Bidirectional Bidirectional Bidirectional Bidirectional Bidirectional Power supply Clock Clock Ground Bidirectional Bidirectional Bidirectional Bidirectional Bidirectional Bidirectional Bidirectional Bidirectional Bidirectional Ground Bidirectional Bidirectional Bidirectional Bidirectional Power Bidirectional Bidirectional Bidirectional Bidirectional Bidirectional Bidirectional Power Bidirectional Bidirectional Description Universal I/O Controller 0, pin 0 Universal I/O Controller 0, pin 1 Universal I/O Controller 0, pin 2 Universal I/O Controller 0, pin 3 Digital ground Universal I/O Controller 0, pin 4 Universal I/O Controller 0, pin 5 Universal I/O Controller 0, pin 6 Universal I/O Controller 0, pin 7 Universal I/O Controller 0, pin 8 Power Supply for the Crystal Oscillator (+2.5VDC) Crystal input pin 0 (Osc. In) Crystal input/output pin 1 (Osc. Out) Digital ground Universal I/O Controller 0, pin 9 Universal I/O Controller 0, pin 10 Universal I/O Controller 0, pin 11 Universal I/O Controller 0, pin 12 Universal I/O Controller 0, pin 13 Universal I/O Controller 0, pin 14 Universal I/O Controller 0, pin 15 Universal I/O Controller 0, pin 16 Universal I/O Controller 0, pin 17 Digital ground Universal I/O Controller 1, pin 0 Universal I/O Controller 1, pin 1 Universal I/O Controller 1, pin 2 Universal I/O Controller 1, pin 3 Digital I/O supply voltage (+3.3VDC) Universal I/O Controller 1, pin 4 Universal I/O Controller 1, pin 5 Universal I/O Controller 1, pin 6 Universal I/O Controller 1, pin 7 Universal I/O Controller 1, pin 8 Universal I/O Controller 1, pin 9 Digital core supply voltage (+2.5VDC) Universal I/O Controller 1, pin 10 Universal I/O Controller 1, pin 11 IA211080807-11 UNCONTROLLED WHEN PRINTED OR COPIED Page 30 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller Data Sheet September 10, 2014 Table 4. BGA 15- by 15-mm Package Pin Listing (Continued) Pin C17 D16 B17 N14 E15 C16 A17 J14 B16 C15 D15 F14 P9 C14 B15 A16 A15 P4 B14 C13 A14 B13 K4 C12 A13 B12 A12 P5 C11 B11 A11 A10 P10 B10 C10 A9 B9 Signal Name UIC1_12 UIC1_13 UIC1_14 GND UIC1_15 UIC1_16 UIC1_17 VDDIO UIC2_0 UIC2_1 UIC2_2 UIC2_3 VDDC UIC2_4 UIC2_5 UIC2_6 UIC2_7 GND UIC2_8 UIC2_9 UIC2_10 UIC2_11 VDDIO UIC2_12 UIC2_13 UIC2_14 UIC2_15 GND UIC2_16 UIC2_17 UIC3_0 UIC3_1 VDDC UIC3_2 UIC3_3 UIC3_4 UIC3_5 Type Bidirectional Bidirectional Bidirectional Ground Bidirectional Bidirectional Bidirectional Power Bidirectional Bidirectional Bidirectional Bidirectional Power Bidirectional Bidirectional Bidirectional Bidirectional Ground Bidirectional Bidirectional Bidirectional Bidirectional Power Bidirectional Bidirectional Bidirectional Bidirectional Ground Bidirectional Bidirectional Bidirectional Bidirectional Power Bidirectional Bidirectional Bidirectional Bidirectional Description Universal I/O Controller 1, pin 12 Universal I/O Controller 1, pin 13 Universal I/O Controller 1, pin 14 Digital ground Universal I/O Controller 1, pin 15 Universal I/O Controller 1, pin 16 Universal I/O Controller 1, pin 17 Digital I/O supply voltage (+3.3VDC) Universal I/O Controller 2, pin 0 Universal I/O Controller 2, pin 1 Universal I/O Controller 2, pin 2 Universal I/O Controller 2, pin 3 Digital core supply voltage (+2.5VDC) Universal I/O Controller 2, pin 4 Universal I/O Controller 2, pin 5 Universal I/O Controller 2, pin 6 Universal I/O Controller 2, pin 7 Digital ground Universal I/O Controller 2, pin 8 Universal I/O Controller 2, pin 9 Universal I/O Controller 2, pin 10 Universal I/O Controller 2, pin 11 Digital I/O supply voltage (+3.3VDC) Universal I/O Controller 2, pin 12 Universal I/O Controller 2, pin 13 Universal I/O Controller 2, pin 14 Universal I/O Controller 2, pin 15 Digital ground Universal I/O Controller 2, pin 16 Universal I/O Controller 2, pin 17 Universal I/O Controller 3 pin 0 Universal I/O Controller 3 pin 1 Digital core supply voltage (+2.5VDC) Universal I/O Controller 3 pin 2 Universal I/O Controller 3 pin 3 Universal I/O Controller 3 pin 4 Universal I/O Controller 3 pin 5 IA211080807-11 UNCONTROLLED WHEN PRINTED OR COPIED Page 31 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller Data Sheet September 10, 2014 Table 4. BGA 15- by 15-mm Package Pin Listing (Continued) Pin C9 A8 B8 A7 P8 C8 B7 A6 A5 B6 C7 A4 B5 C6 A3 Signal Name UIC3_6 UIC3_7 UIC3_8 UIC3_9 VDDIO UIC3_10 UIC3_11 UIC3_12 UIC3_13 GND UIC3_14 UIC3_15 UIC3_16 UIC3_17 T0IC0_T0OC0 Type Bidirectional Bidirectional Bidirectional Bidirectional Power Bidirectional Bidirectional Bidirectional Bidirectional Ground Bidirectional Bidirectional Bidirectional Bidirectional Bidirectional B4 T0IC1_T0OC1 Bidirectional A2 T0IC2_T0OC2 Bidirectional C5 T0IC3_T0OC3 Bidirectional P13 B3 GND T1IC0_T1OC0 Ground Bidirectional A1 T1IC1_T1OC1 Bidirectional B2 T1IC2_T1OC2 Bidirectional C4 T1IC3_T1OC3 Bidirectional C3 D6 P14 H14 T0IN T1IN GND VDDIO Input Input Ground Power Description Universal I/O Controller 3 pin 6 Universal I/O Controller 3 pin 7 Universal I/O Controller 3 pin 8 Universal I/O Controller 3 pin 9 Digital I/O supply voltage (+3.3VDC) Universal I/O Controller 3 pin 10 Universal I/O Controller 3 pin 11 Universal I/O Controller 3 pin 12 Universal I/O Controller 3 pin 13 Digital Ground Universal I/O Controller 3 pin 14 Universal I/O Controller 3 pin 15 Universal I/O Controller 3 pin 16 Universal I/O Controller 3 pin 17 Muxed pin, Timer Counter Unit 0 input capture 0 or output compare 0 Muxed pin, Timer Counter Unit 0 input capture 1 or output compare 1 Muxed pin, Timer Counter Unit 0 input capture 2 or output compare 2 Muxed pin, Timer Counter Unit 0 input capture 3 or output compare 3 Digital ground Muxed pin, Timer Counter Unit 1 input capture 0 or output compare 0 Muxed pin, Timer Counter Unit 1 input capture 1 or output compare 1 Muxed pin, Timer Counter Unit 1 input capture 2 or output compare 2 Muxed pin, Timer Counter Unit 1 input capture 3 or output compare 3 Timer Counter Unit 0 external clock source Timer Counter Unit 1 external clock source Digital Ground Digital I/O supply voltage (+3.3VDC) IA211080807-11 UNCONTROLLED WHEN PRINTED OR COPIED Page 32 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller 4.2.2 Data Sheet September 10, 2014 BGA 15- by 15-mm Physical Package Dimensions The physical dimensions for the BGA 15- by 15-mm package are as shown in Figure 5. Notes: 1. Controlling dimension: Millimeter. 2. Primary datum C and seating plane are defined by the spherical crowns of the solder balls. 3. Dimension b is measured at the maximum solder-ball diameter, parallel to primary datum C. 4. There will be a minimum clearance of 0.25 mm between the edge of the solder ball and the body edge. 5. Special Characteristics C Class: bbb ddd. 6. The pattern of Pin 1 fiducial is for reference only. Legend: Dimension in mm Symbol A A1 A2 c D E D1 E1 e b aaa bbb ddd eee fff MD/ME MIN – 0.16 0.84 0.32 14.90 14.90 – – – 0.25 NOM – 0.21 0.89 0.36 15.00 15.00 12.80 12.80 0.80 0.30 0.10 0.10 0.12 0.15 0.08 17/17 MAX 1.20 0.26 0.94 0.40 15.10 15.10 – – – 0.35 Dimension in Inches MIN – 0.006 0.033 0.013 0.587 0.587 – – – 0.010 NOM – 0.008 0.035 0.014 0.591 0.591 0.504 0.504 0.031 0.012 0.004 0.004 0.005 0.006 0.003 17/17 MAX 0.047 0.010 0.037 0.016 0.594 0.594 – – – 0.014 Figure 5. BGA 15- by 15-mm Physical Package Dimensions IA211080807-11 UNCONTROLLED WHEN PRINTED OR COPIED Page 33 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller 4.2.3 Data Sheet September 10, 2014 BGA 15- by 15-mm Signal Routing The 15- by15-mm BGA can be easily routed using economical and readily available PCB fabrication design rules. In order to route all signals from the fido1100 BGA, 2 layers in addition to power and ground are required, using 0.1mm trace/space technology. Since 0.1mm = 3.937mil, most PCB fabricators will consider this 4mil trace/space. The PCB land pattern for the BGA should use 0.3mm round pads. Since the BGA pitch is 0.8mm, this leaves 0.5mm of space between pads. Using 0.1mm trace/space, 2 signals may be routed between each pair of pads (2 traces + 3spaces = 0.5mm). Figure 8 shows how this is accomplished. Referring to Figure 6, signal layer 1 is shown in black, signal layer 2 is shown in red, and the vias are shown in blue. Signal layer 1 is the top side with the BGA pads, while signal layer 2 may be any other layer, but is typically the bottom side. All vias with no trace routed out from the BGA are power or ground. Note that the innermost row of pads is all power and ground, except for 9 pads which are signals. Three of these signals are easily routed on signal layer 1, but 6 of them require the use of vias and signal layer 2. If all of the signals are not required for a given design, it may be possible to route all of the used signals on signal layer 1. It may be beneficial to place more vias and to route more signals on layers other than signal layer 1. This could produce a better PCB layout, but care should be exercised to not include an excessive number of vias. The use of too many vias can lead to inadequate copper on the power/ground plane layers surrounding the center area of the BGA, resulting in relative isolation of the BGA power/ground via connections. Note the open space between pads M17 and N17 (A1 is upper left corner). These signals are XTAL1 and XTAL0. It is best not to route other signals between these pads, especially if a crystal is used for the clock source. The power connections to the inner ring of pads have 4 vias for +3.3V and 4 vias for +2.5V. The use of a single bypass capacitor for each via, and alternating 0.1uF and 0.01uF values on each supply, provide reasonable bypass capacitance for the fido1100. Using 8 capacitors in this manner allows the use of capacitors in the 0603 package for economical PCB assembly. IA211080807-11 UNCONTROLLED WHEN PRINTED OR COPIED Page 34 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller Data Sheet September 10, 2014 Figure 6. BGA 15- by 15-mm Signal Routing IA211080807-11 UNCONTROLLED WHEN PRINTED OR COPIED Page 35 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller 4.3 Data Sheet September 10, 2014 Power and Ground Signals Tables 5 - 9 provide analog power and ground signals, crystal oscillator power and ground signals, 2.5 VDC digital core power signals, 3.3 VDC digital IO power signals, and digital ground signals, respectively. The recommended bypass capacitors for the fido1100 are: • Use a mix of 0.1 µf and 0.01 µf capacitors. • Bypass capacitors should be located as close as possible to power pins they are connected to. Table 5. Analog Power and Ground Signals BGA PQFP 15 x 15 11 D1 12 E1 Signal Name VDDA GNDA Type Power Ground Description Analog supply voltage (+3.3VDC) Analog ground Table 6. Crystal Oscillator Power and Ground Signals BGA PQFP 15 x 15 117 M15 120 M14 Signal Name VDDCLK GNDCLK Type Description Power supply Power Supply for the Crystal Oscillator (+2.5VDC) Ground Digital ground Table 7. 2.5 VDC Digital Core Power Signals BGA PQFP 15 x 15 Signal Name 16 D7 VDDC 48 D8 VDDC 75 D9 VDDC 80 H4 VDDC 106 K14 VDDC 142 L14 VDDC 157 P9 VDDC 177 P10 VDDC 206 – VDDC – – VDDC Type Power Power Power Power Power Power Power Power Power Power Description Digital core supply voltage (+2.5VDC) Digital core supply voltage (+2.5VDC) Digital core supply voltage (+2.5VDC) Digital core supply voltage (+2.5VDC) Digital core supply voltage (+2.5VDC) Digital core supply voltage (+2.5VDC) Digital core supply voltage (+2.5VDC) Digital core supply voltage (+2.5VDC) Digital core supply voltage (+2.5VDC) Digital core supply voltage (+2.5VDC) IA211080807-11 UNCONTROLLED WHEN PRINTED OR COPIED Page 36 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller Data Sheet September 10, 2014 Table 8. 3.3 VDC Digital IO Power Signals BGA PQFP 15 x 15 Signal Name 22 D10 VDDIO 37 D11 VDDIO 65 D12 VDDIO 85 G14 VDDIO 135 J4 VDDIO 152 J14 VDDIO 167 K4 VDDIO 187 P8 VDDIO – H14 VDDIO Type Power Power Power Power Power Power Power Power Power Description Digital I/O supply voltage (+3.3VDC) Digital I/O supply voltage (+3.3VDC) Digital I/O supply voltage (+3.3VDC) Digital I/O supply voltage (+3.3VDC) Digital I/O supply voltage (+3.3VDC) Digital I/O supply voltage (+3.3VDC) Digital I/O supply voltage (+3.3VDC) Digital I/O supply voltage (+3.3VDC) Digital I/O supply voltage (+3.3VDC) Table 9. Digital Ground Signals BGA PQFP 15 x 15 Signal Name 31 D4 GND 42 T1 GND 44 D5 GND 53 P6 GND 60 D13 GND 70 D14 GND 90 E4 GND 111 E14 GND 130 N4 GND 148 N14 GND 162 P4 GND 172 P5 GND 182 B6 GND 192 P13 GND 201 P14 GND – – GND Type Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Description Digital ground Digital ground Digital ground Digital Ground Digital ground Digital ground Digital ground Digital ground Digital ground Digital ground Digital ground Digital ground Digital ground Digital Ground Digital ground Digital Ground IA211080807-11 UNCONTROLLED WHEN PRINTED OR COPIED Page 37 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller 5. Data Sheet September 10, 2014 Electrical Characteristics Tables 10 - 14 show the absolute maximum ratings, ESD and latch-up characteristics, recommended operating conditions, DC characteristics, and input impedance, respectively. Table 10. Absolute Maximum Ratings Symbol VDDC VDDIO VAIN TA TS TJ Parameter Name Digital core supply voltage Digital I/O supply voltage Analog input voltage with respect to ground Ambient temperature Storage temperature Junction Temperature Conditions – – – – – – Min -0.3 -0.3 -0.3 -40 -55 -40 Typ – – – – – – Max 3.05 5.5 3.9 +85 +150 +125 Units V V V o C o C o C Note: Operation of the fido1100 outside of maximum operating ratings may result in failure of the device. Table 11. ESD and Latch-Up Characteristics Symbol VHBM VMM ILATP ILATN Parameter Name Human body model Machine model Positive latch-up current Negative latch-up current Conditions – – – – Min 2000 200 – – Typ – – – – Max – – 50 -50 Units V V µA µA Table 12. Recommended Operating Conditions Symbol VDDC VDDIO fXTAL TA VDDA VRH VRL CL Parameter Name Digital core supply voltage Digital I/O supply voltage Crystal frequency Ambient temperature Analog supply voltage ADC reference voltage—high ADC reference voltage—low Digital output load capacitance Conditions – – – – – – – See note Min 2.25 3.0 – -40 3.0 – – – Typ 2.5 3.3 – – 3.3 3.0 0 3.1 Max 2.75 3.6 66 +85 3.6 – – – Units V V MHz o C V V V pF Note: This parameter is guaranteed by design and not tested in production. IA211080807-11 UNCONTROLLED WHEN PRINTED OR COPIED Page 38 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller Data Sheet September 10, 2014 Table 13. DC Characteristics o o TA = –40 C and +85 C; VDDC = 2.5V ± 10%; VDDIO = 3.3V ± 10%; Symbol Parameter Name Conditions Min Typ VIH Input high voltage – 2.0 – VIL Input low voltage – – – ILKG Input leakage current – -10 1 CIN Input capacitance – – 3.6 VOH Output high voltage |IOH| = 8 mA 2.4 – VOL Output low voltage |IOL| = 8 mA – – IOZ Tri-state leakage – -10 1 COUT Package output capacitance – – 3.6 FCLK = 66MHz Max Units – V 0.8 V 10 µA – pF – V 0.4 V 10 µA – pF Table 14. Input Impedance Input leakage current: Tristate leakage current: Pin capacitance (input or output): ± 10 µA with no pull-up/pull-down ± 10 µA ~3.5 pF not including package contribution Table 15. AC Characteristics of Crystal Oscillator Symbol fOSC tST Parameter Crystal oscillator range Startup time Conditions TA = 25ºC TA = 25ºC Typ – 20 Max 66 – Units MHz ms IA211080807-11 UNCONTROLLED WHEN PRINTED OR COPIED Page 39 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller Data Sheet September 10, 2014 Table 16. Analog-to-Digital Converter Characteristics Symbol VINA CINA Res INL DNL SINAD FSMPL PD SMP Parameter Name Conditions Min Input voltage range – 0.1VDDA Input capacitance – – Resolution – – Integral non-linearity – – Differential non-linearity guaranteed no missing codes – Signal to noise plus distortion Fin = 10 KHz – Sample clock frequency – 0.5 Power dissipation TA = 25ºC – Sample rate – – Typ 20 10 ±2 ±1 54 – 5 – Max 0.9VDDA – – – – – 2.6 – 200 Units V pF Bits Lsb Lsb dB MHz mW Ksps Notes: 1. The ADC in the fido1100 uses its own VDD (VDDA) and GND (GNDA) connections along with VREF High (VRH) and VREF Low (VRL) signals. 2. VRH must be less than or equal to VDDA. 3. VRL must be greater than or equal to GNDA. 4. To ensure maximum conversion accuracy, VDDA, GNDA, VRH, and VRL should be as clean and free of noise as possible. Table 17. Power Consumption Conditions Core Voltage 2.5 VDC Current Power I/O Voltage 3.3 VDC Current Power Total Power Halted after a Reset 109.240 mA 273.100 mW 2.500 mA 8.25 mW 281.35 mW Light Processing Load 214.000 mA 535.000 mW 7.700 mA 25.41 mW 560.41 mW Heavy Processing Load 227.000 mA 567.500 mW 17.000 mA 56.1 mW 623.60 mW Sleep Mode 320.90 mW Stop Mode 302.91 mW Low Power Stop Mode (LPSTOP) 8.68 mW IA211080807-11 UNCONTROLLED WHEN PRINTED OR COPIED Page 40 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller 6. Data Sheet September 10, 2014 Thermal Characteristics The thermal resistance characteristics for the 28 x 28 mm PQFP and the 15 x 15 mm BGA packages are provided in Table 18. All data is simulated based on the 2S2P board type. The board type is defined by JEDEC standard JESD51-7 for the PQFP package and by JESD51-9 for the BGA package. Table 18. Thermal Resistance Characteristics Name Description Airflow (m/S) 15 x 15 mm BGA 28 x 28 mm PQFP θJC (°C/W) Junction to Case 0 7.2 16.3 θJA (°C/W) Junction to Ambient 0 56.8 35.1 θJA (°C/W) Junction to Ambient 1 51.1 30.9 θJA (°C/W) Junction to Ambient 2 48.8 28.7 θJA (°C/W) Junction to Ambient 3 47.2 27.5 IA211080807-11 UNCONTROLLED WHEN PRINTED OR COPIED Page 41 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller 7. Reset 7.1 Overview Data Sheet September 10, 2014 This section describes the reset signal considerations and the reset timing. The Power On Reset Register has a control bit to determine whether Major Reset or Minor Reset processing is performed after reset is asserted. The section below presents the hardware signal characteristics. See The fido1100 User Guide for more details on the Power On Reset Control Register. 7.2 Signal Considerations and Reset Timing The fido1100 requires the RESET_N signal to be asserted LOW for a minimum of 100 µS after VDDIO and VDDC are at their nominal values and stable. The RESET_N signal must have a rise time of less than 100 nS. Table 19 presents the hardware signals involved or affected and should be considered when asserting reset. Table 19. Hardware Signals Involved When Asserting Reset Signal Name RESET_N RESET_OUT_N A_25_RESET_DELAY A27_CS7_N Type Input Output Muxed, Internal Pull-up Muxed, Internal Pull-up Muxed A28_CS6_N Muxed A29_CS5_N Muxed A30_CS4_N Muxed CS0_N Output A_26_SIZE Description Reset input Reset output Muxed pin, External Bus Interface address Bit [25] or POR counter bypass Muxed pin, External Bus Interface address Bit [26] or data bus size select (0 = 8-bit, 1 = 16-bit) Muxed pin, External Bus Interface address Bit [27] or Chip select 7 (chip select active low) Muxed pin, External Bus Interface address Bit [28] or Chip select 6 (chip select active low) Muxed pin, External Bus Interface address Bit [29] or Chip select 5 (chip select active low) Muxed pin, External Bus Interface address Bit [30] or Chip select 4 (chip select active low) Chip select 0 (chip select active low) When RESET_N is asserted, the following sequence occurs: • The A25_Reset_Delay signal is sampled to determine the length of the reset clock delay – Low—reset clock delay → 100 µsecs – High—reset clock delay → 20 msecs Note: After this delay, the part performs major or minor reset processing and is released to run. • The A_26_SIZE pin is sampled for the external bus interface size – Low—8-bit width – High—16-bit width IA211080807-11 UNCONTROLLED WHEN PRINTED OR COPIED Page 42 of 74 http://www.innovasic.com Customer Support: 1-888-824-4184 Flexible Input Deterministic Output (fido®) 32-Bit Real-Time Communications Controller Data Sheet September 10, 2014 • The RESET_OUT_N signal is driven low for the determined clock delay Figures 7 and 8 present the reset timing and extended reset timing diagrams, respectively. The A_26_SIZE signal is not shown, but it is sampled. CLK CLK Clock Running |
