59-14UTD

EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet Luminosity white Color LED 59-14 UTD/TR8 Features ․Super luminosity white LED. ․Built in 4 LED chips. ․Wide viewing angle. ․Soldering methods: Reflow soldering. ․High performance. ․Package in 12mm tape on 7〞diameter reel. ․Pb-free. ․The product itself will remain within RoHS compliant version. Descriptions ․The 59-14 SMD Taping is much smaller than lead frame type components, thus enable smaller board size, higher packing density, reduced storage space and finally smaller equipment to be obtained. ․Besides, lightweight makes them ideal for miniature applications. etc. Applications ․Amusement equipment. ․Information boards. ․Flashlight for digital camera of cellular phone. ․Lighting for small size device. Device Selection Guide Chip Lens Color Material InGaN Emitted Color White Yellow diffused Everlight Electronics Co., Ltd. Device No. : DSE-594-001 http://www.everlight.com Prepared date: 03-Oct-2005 Rev.1 Page: 1 of 10 Prepared by: Jeff Tsai EVERLIGHT ELECTRONICS CO.,LTD. 59-14 UTD/TR8 Package Outline Dimensions 0.3 (1) (2) (3) (4) 5.0 (5) (6) (7) (8) 5.0 1.5 0.3 0.55 1.25 0.475 1.25 0.475 0.55 1.05 (1) (2) (3) (4) 1.05 (5) (6) (7) (8) 1.0 1.25 1.25 1.0 0.45 0.45 0.45 Note: The tolerances unless mentioned is ±0.1mm ,Unit = mm Everlight Electronics Co., Ltd. Device No. : DSE-594-001 http://www.everlight.com Prepared date: 03-Oct-2005 Rev.1 Page: 2 of 10 Prepared by: Jeff Tsai 0.75 3.5 0.75 EVERLIGHT ELECTRONICS CO.,LTD. 59-14 UTD/TR8 Absolute Maximum Ratings (Ta=25℃) Parameter Reverse Voltage Forward Current Operating Temperature Storage Temperature Electrostatic Discharge(HBM) Power Dissipation Peak Forward Current (Duty 1/10 @ 400ms) Soldering Temperature Symbol VR IF Topr Tstg ESD Pd IFP Rating 5 30 -40 ~ +85 -40 ~ +90 1000 110 100 Unit V mA ℃ ℃ V mW mA Reflow Soldering : 260 ℃ for 10 sec. Tsol Hand Soldering : 350 ℃ for 3 sec. * The value are base d on the 1-die performance. Electro-Optical Characteristics (Ta=25℃) Parameter Symbol Min. 5.0 Luminous Intensity*1 Iv 10.0 Viewing Angle*1 Forward Voltage*2 Typ. 8.5 25.0 60 3.3 4.4 ----- Max. 15.0 Unit Condition IF=20mA*2 cd 45.0 ----3.7 V 3.6 5.2 50 μA deg IFP=100mA*2 (Duty 1/10 @ 400ms) IF=20mA*2 IF=20mA*2 IFP=100mA*2 (Duty 1/10 @ 400ms) VR=5V*2 2θ1/2 ----2.7 VF Forward Voltage*2 Reverse Current*2 IR ----- *1 When 4 LED dies are operated simultaneously. *2 For each die. Note: The products are sensitive to static electricity and care must be fully taken when handling products. Everlight Electronics Co., Ltd. Device No. : DSE-594-001 http://www.everlight.com Prepared date: 03-Oct-2005 Rev.1 Page: 3 of 10 Prepared by: Jeff Tsai EVERLIGHT ELECTRONICS CO.,LTD. 59-14 UTD/TR8 Color Ranks x y 0.280 0.248 Rank A0 0.264 0.283 0.267 0.305 0.296 0.276 x y 0.287 0.295 Rank B3 0.283 0.304 0.305 0.330 0.307 0.315 Rank B4 x y 0.307 0.315 0.304 0.330 0.330 0.360 0.330 0.339 x y 0.296 0.276 Rank B5 0.287 0.295 0.307 0.315 0.311 0.294 x y 0.311 0.294 Rank B6 0.307 0.330 0.315 0.339 0.330 0.318 x y 0.330 0.318 Rank C0 0.330 0.361 0.360 0.385 0.356 0.351 *The C.I.E. 1931 chromaticity diagram ( Tolerance ±0.01). CIE Chromaticity Diagram Everlight Electronics Co., Ltd. Device No. : DSE-594-001 http://www.everlight.com Prepared date: 03-Oct-2005 Rev.1 Page: 4 of 10 Prepared by: Jeff Tsai EVERLIGHT ELECTRONICS CO.,LTD. 59-14 UTD/TR8 Typical Electro-Optical Characteristics Curves Everlight Electronics Co., Ltd. Device No. : DSE-594-001 http://www.everlight.com Prepared date: 03-Oct-2005 Rev.1 Page: 5 of 10 Prepared by: Jeff Tsai EVERLIGHT ELECTRONICS CO.,LTD. 59-14 UTD/TR8 Label explanation CAT: Luminous Intensity Rank HUE: Chromaticity Coordinates REF: Forward Voltage Rank Reel Dimensions Note: The tolerances unless mentioned is ±0.1mm ,Unit = mm Everlight Electronics Co., Ltd. Device No. : DSE-594-001 http://www.everlight.com Prepared date: 03-Oct-2005 Rev.1 Page: 6 of 10 Prepared by: Jeff Tsai EVERLIGHT ELECTRONICS CO.,LTD. 59-14 UTD/TR8 Carrier Tape Dimensions: Taping Quantity: 800pcs (4) (3) (2) (1) (8) (4) (7) (3) (6) (2) (5) (1) (8) (7) (6) (5) Note: The tolerances unless mentioned is ±0.1mm ,Unit = mm Moisture Resistant Packaging Label Aluminum moisture-proof bag Desiccant Label Everlight Electronics Co., Ltd. Device No. : DSE-594-001 http://www.everlight.com Prepared date: 03-Oct-2005 Rev.1 Page: 7 of 10 Prepared by: Jeff Tsai EVERLIGHT ELECTRONICS CO.,LTD. 59-14 UTD/TR8 Reliability Test Items And Conditions The reliability of products shall be satisfied with items listed below. Confidence level：90% LTPD：10% No. 1 Items Reflow Soldering Test Condition Temp. : 260℃±5℃ Min. 5sec. H : +100℃ 15min ∫ 5 min L : -40℃ 15min H : +100℃ 5min ∫ 10 sec L : -10℃ 5min Temp. : 100℃ Temp. : -40℃ IF = 20 mA 85℃/ 85%RH Test Sample Hours/Cycles Size 6 Min. 300 Cycles 22 PCS. Ac/Re 0/1 2 Temperature Cycle 22 PCS. 0/1 3 Thermal Shock High Temperature Storage Low Temperature Storage DC Operating Life High Temperature / High Humidity 300 Cycles 1000 Hrs. 1000 Hrs. 1000 Hrs. 1000 Hrs. 22 PCS. 0/1 4 5 6 7 22 PCS. 22 PCS. 22 PCS. 22 PCS. 0/1 0/1 0/1 0/1 Everlight Electronics Co., Ltd. Device No. : DSE-594-001 http://www.everlight.com Prepared date: 03-Oct-2005 Rev.1 Page: 8 of 10 Prepared by: Jeff Tsai EVERLIGHT ELECTRONICS CO.,LTD. 59-14 UTD/TR8 Precautions For Use 1. Over-current-proof Customer must apply resistors for protection, otherwise slight voltage shift will cause big current change ( Burn out will happen ). 2. Storage 2.1 Do not open moisture proof bag before the products are ready to use. 2.2 Before opening the package: The LEDs should be kept at 30℃ or less and 90%RH or less. 2.3 After opening the package: The LED's floor life is 1 year under 30 deg C or less and 60% RH or less. If unused LEDs remain, it should be stored in moisture proof packages. 2.4 If the moisture absorbent material (silica gel) has faded away or the LEDs have exceeded the storage time, baking treatment should be performed using the following conditions. Baking treatment : 60±5℃ for 24 hours. 3. Soldering Condition 3.1 Pb-free solder temperature profile 3.2 Reflow soldering should not be done more than two times. 3.3 When soldering, do not put stress on the LEDs during heating. 3.4 After soldering, do not warp the circuit board. Everlight Electronics Co., Ltd. Device No. : DSE-594-001 http://www.everlight.com Prepared date: 03-Oct-2005 Rev.1 Page: 9 of 10 Prepared by: Jeff Tsai EVERLIGHT ELECTRONICS CO.,LTD. 59-14 UTD/TR8 4.Soldering Iron Each terminal is to go to the tip of soldering iron temperature less than 350℃ for 3 seconds within once in less than the soldering iron capacity 25W. Leave two seconds and more intervals, and do soldering of each terminal. Be careful because the damage of the product is often started at the time of the hand solder. 5.Repairing Repair should not be done after the LEDs have been soldered. When repairing is unavoidable, a double-head soldering iron should be used (as below figure). It should be confirmed beforehand whether the characteristics of the LEDs will or will not be damaged by repairing. EVERLIGHT ELECTRONICS CO., LTD. Office: No 25, Lane 76, Sec 3, Chung Yang Rd, Tucheng, Taipei 236, Taiwan, R.O.C Tel: 886-2-2267-2000, 2267-9936 Fax: 886-2267-6244, 2267-6189, 2267-6306 http://www.everlight.com Everlight Electronics Co., Ltd. Device No. : DSE-594-001 http://www.everlight.com Prepared date: 03-Oct-2005 Rev.1 Page: 10 of 10 Prepared by: Jeff Tsai
