JIANGSU CHANGJIANG ELECTRONICS TECHNOLOGY CO., LTD
SOT-23 Plastic-Encapsulate MOSFETS
CJ2302S N-Channel 20-V(D-S) MOSFET
V(BR)DSS
20 V
ID
RDS(on)MAX
SOT-23
60mΩ@4.5V
2.1A
115mΩ@ 2.5V
1. GATE
2. SOURCE
3. DRAIN
FEATURE
z TrenchFET Power MOSFET
APPLICATION
z
Load Switch for Portable Devices
z
DC/DC Converter
MARKING
Equivalent Circuit
Maximum ratings (Ta=25℃ unless otherwise noted)
Parameter
Unit
Symbol
Value
Drain-Source Voltage
VDS
20
Gate-Source Voltage
VGS
±8
Continuous Drain Current (TJ=150℃)
ID
2.1
Pulsed Drain Current
IDM
10
Continuous Source-Drain Current(Diode Conduction)
IS
0.6
Power Dissipation
PD
0.35
W
RθJA
357
℃/W
Operating Junction
TJ
150
Storage Temperature
TSTG
-55 ~+150
Thermal Resistance from Junction to Ambient (t≤5s)
www.cj-elec.com
1
V
A
℃
D,Aug,2015
MOSFET ELECTRICAL CHARACTERISTICS
Ta =25 ℃ unless otherwise specified
Parameter
Symbol
Test Condition
Min
Typ
Max
0.95
1.2
Units
Static
Drain-source breakdown voltage
V(BR)DSS
VGS = 0V, ID =10µA
20
VGS(th)
VDS =VGS, ID =50µA
0.65
Gate-body leakage
IGSS
VDS =0V, VGS =±8V
±100
nA
Zero gate voltage drain current
IDSS
VDS =20V, VGS =0V
1
µA
Gate-threshold voltage
VGS =4.5V, ID =3.6A
0.035
0.060
VGS =2.5V, ID =3.1A
0.045
0.115
Drain-source on-resistancea
rDS(on)
Forward transconductancea
gfs
VDS =5V, ID =3.6A
8
Diode forward voltage
VSD
IS=0.94A,VGS=0V
0.76
1.2
4.0
10
V
Ω
S
V
Dynamic
Total gate charge
Qg
Gate-source charge
Qgs
Gate-drain charge
Qgd
1.5
Input capacitance
Ciss
300
Output capacitance
Coss
Reverse transfer capacitance
Crss
VDS =10V,VGS =4.5V,ID =3.6A
VDS =10V,VGS =0V,f=1MHz
nC
0.65
pF
120
80
Switching
Turn-on delay time
Rise time
Turn-off delay time
Fall time
td(on)
tr
td(off)
tf
VDD=10V,
RL=5.5Ω, ID ≈3.6A,
VGEN=4.5V,Rg=6Ω
7
15
55
80
16
60
10
25
ns
Notes :
a. Pulse Test : Pulse width≤300µs, duty cycle ≤2%.
www.cj-elec.com
2
D,Aug,2015
Typical Characteristics
Transfer Characteristics
Output Characteristics
20
VGS=3.5、3.0、2.5V
10
Ta=25℃
Ta=25℃
Pulsed
Pulsed
8
15
(A)
VGS=1.5V
5
ID
10
6
DRAIN CURRENT
DRAIN CURRENT
ID
(A)
VGS=2.0V
4
2
0
0
2
4
6
DRAIN TO SOURCE VOLTAGE
RDS(ON)
120
——
8
VDS
0
0.0
10
(V)
0.5
1.0
1.5
GATE TO SOURCE VOLTAGE
RDS(ON)
ID
——
2.0
VGS
VGS
300
Ta=25℃
Ta=25℃
Pulsed
Pulsed
250
(mΩ)
200
RDS(ON)
80
VGS=2.5V
ON-RESISTANCE
ON-RESISTANCE
RDS(ON)
(mΩ)
100
60
VGS=4.5V
40
20
2.5
(V)
150
100
ID=3.6A
50
0
5
10
15
DRAIN CURRENT
10
IS
——
20
ID
25
30
(A)
0
0
2
4
6
GATE TO SOURCE VOLTAGE
8
VGS
10
(V)
VSD
Ta=25℃
SOURCE CURRENT
IS
(A)
Pulsed
1
0.1
0.0
0.4
0.8
1.2
SOURCE TO DRAIN VOLTAGE
1.6
VSD
2.0
(V)
3 D,Aug,2015
SOT-23 Package Outline Dimensions
Symbol
A
A1
A2
b
c
D
E
E1
e
e1
L
L1
θ
Dimensions In Millimeters
Min
Max
0.900
1.150
0.000
0.100
0.900
1.050
0.300
0.500
0.080
0.150
2.800
3.000
1.200
1.400
2.250
2.550
0.950 TYP
1.800
2.000
0.550 REF
0.300
0.500
0°
8°
Dimensions In Inches
Min
Max
0.035
0.045
0.000
0.004
0.035
0.041
0.012
0.020
0.003
0.006
0.110
0.118
0.047
0.055
0.089
0.100
0.037 TYP
0.071
0.079
0.022 REF
0.012
0.020
0°
8°
SOT-23 Suggested Pad Layout
www.cj-elec.com
4
D,Aug,2015
SOT-23 Tape and Reel
SOT-23 Tape and reel
SOT-23 Embossed Carrier Tape
P0
d
P1
Packaging Description:
SOT-23 parts are shipped in tape. The carrier
tape is made from a dissipative (carbon filled)
polycarbonate resin. The cover tape is a multilayer
film (Heat Activated Adhesive in nature) primarily
composed of polyester film, adhesive layer, sealant,
and anti-static sprayed agent. These reeled parts in
standard option are shipped with 3,000 units per 7"
or 17.8cm diameter reel. The reels are clear in color
and is made of polystyrene plastic (anti-static
coated).
B
W
A
F
E
C
A
A
P
A-A
Dimensions are in millimeter
Pkg type
A
B
C
d
E
F
P0
P
P1
W
SOT-23
3.15
2.77
1.22
Ø1.50
1.75
3.50
4.00
4.00
2.00
8.00
SOT-23 Tape Leader and Trailer
Trailer Tape
Leader Tape
100±2 Empty Pockets
Components
50±2 Empty Pockets
SOT-23 Reel
D
I
G
W2
3000
H
2500
2000
1500
1000
D2
D1
500
W1
Dimensions are in millimeter
Reel Option
D
D1
D2
G
H
I
W1
W2
7''Dia
Ø178.00
54.40
13.00
R78.00
R25.60
R6.50
9.50
12.30
G.W.(kg)
REEL
Reel Size
Box
Box Size(mm)
Carton
Carton Size(mm)
3000 pcs
7 inch
30,000 pcs
203×203×195
120,000 pcs
438×438×220
www.cj-elec.com
5
D,Aug,2015
