S8550T
TRANSISTOR
(PNP)
SOT-523
FEATURES
Complimentary to S8050T
1. BASE
2. EMITTER
Collector current: IC=0.5A
MARKING :
3. COLLECTOR
2TY
MAXIMUM RATINGS (TA=25℃ unless otherwise noted)
Symbol
Parameter
Value
Units
VCBO
Collector-Base Voltage
-40
V
VCEO
Collector-Emitter Voltage
-25
V
VEBO
Emitter-Base Voltage
-5
V
IC
Collector Current -Continuous
-0.5
A
PC
Collector Power Dissipation
0.2
W
Tj
Junction Temperature
150
℃
Tstg
Storage Temperature
-55-150
℃
ELECTRICAL CHARACTERISTICS (Tamb=25℃ unless otherwise specified)
Symbol
Parameter
Test
conditions
Collector-base breakdown voltage
V(BR)CBO
IC = -100µA,
Collector-emitter breakdown voltage
V(BR)CEO
Emitter-base breakdown voltage
MIN
MAX
UNIT
-40
V
IC =-1mA, IB=0
-25
V
V(BR)EBO
IE= -100µA, IC=0
-5
V
Collector cut-off current
ICBO
VCB= -40V, IE=0
-0.1
µA
Collector cut-off current
ICEO
VCE= -20V, IB=0
-0.1
µA
Emitter cut-off current
IEBO
VEB= -3V, IC=0
-0.1
µA
IE=0
hFE(1)
VCE= -1V, IC= -50mA
120
400
hFE(2)
VCE= -1V, IC= -500mA
50
Collector-emitter saturation voltage
VCE(sat)
IC=-500mA, IB= -50mA
-0.6
V
Base-emitter saturation voltage
VBE(sat)
IC=-500mA, IB= -50mA
-1.2
V
DC current gain
VCE= -6V, IC= -20mA
fT
Transition frequency
f=30MHz
150
MHz
CLASSIFICATION OF hFE(1)
Rank
Range
Page 1 of 3
L
H
J
120-200
200-350
300-400
4 /22/2019
Typical Characteristics
Page 2 of 3
S8550T
4 /22/2019
Page 3 of 3
4 /22/2019
